Managing OmniSwitch 6450 Stacks Expansion Modules and Stacking Mode Detection
OmniSwitch 6450 Hardware Users Guide July 2012 page 6-3
Expansion Modules and Stacking Mode Detection
By default, 24- and 48-port OmniSwitch 6450 switches are set to stackable mode.
Note. 10-port OmniSwitch 6450 switches do not support stacking and operate in standalone mode only.
The switch’s stacking mode (stackable versus standalone) is configured through auto-detection. During
the boot process, the switch determines the type of expansion module installed and sets the stacking
mode accordingly.
Swapping Expansion Modules
A reboot is required when adding or swapping “unlike” module types (e.g., a 10G stacking module is
being swapped with a 1G uplink module) or when a 1G uplink module is being added to an empty module
slot. Refer to the table below for more information:
Note. Because the switch uses auto-detection to determine whether stacking mode is needed, the
stack set slot mode command is not supported.
Expansion Module Being
Installed
Expansion Module Being
Replaced
Reboot
Required?
Mode Following
Installation
10G (OS6450-XNI-U2) None (empty slot) No stackable
10G (OS6450-XNI-U2) 10G (OS6450-XNI-U2) No stackable
10G (OS6450-XNI-U2) 1G (OS6450-GNI-C2/U2) Yes stackable
1G (OS6450-GNI-C2/U2) None (empty slot) Yes standalone
1G (OS6450-GNI-C2/U2) 1G (OS6450-GNI-C2/U2) No standalone
1G (OS6450-GNI-C2/U2) 10G (OS6450-XNI-U2) Yes standalone
