Alcatel-Lucent OmniSwitch 6860N User Manual

Chassis and Power Supplies OmniSwitch 6860 Chassis Details
OmniSwitch 6860 Hardware Users Guide October 2022 page 3-33
OmniSwitch 6860N Uplink Modules
OS68-XNI-U4 Front Panel
OS68-QNI-U2 Front Panel
Item Description
A
Status LEDs
B
(4) SFP+ (1G/10G) ports
Item Description
A
Status LEDs
B
(2) QSFP+ (40G) ports
A
B
A
B

Alcatel-Lucent OmniSwitch 6860N Specifications

General

Model	OmniSwitch 6860N
Switching Capacity	Up to 176 Gbps
Jumbo Frame Support	Yes
Type	Network Switch
Uplink Ports	4 x 10G SFP+ ports
MAC Address Table Size	32K
Power Supply	AC or DC
Dimensions (H x W x D)	4.4 x 44 x 35 cm (1.73 x 17.32 x 13.78 in)
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	10% to 90% (non-condensing)
Management	CLI, SNMP
Features	Layer 2/3 switching, IPv4/IPv6, QoS
Form Factor	1U rack-mountable
Ports	24 or 48 x 10/100/1000Base-T ports
