Alcatel-Lucent OXO Connect 8078s - Page 101

Accessories
8AL90340ENADed01
101 /115
Connect the device
Phone set connected over IP and to an external power suply
Connected to the DC power jack of the desk phone by using DC Japan
cable.
Connected to the power supply of the device.
Connected to the SATA connector of the desk phone, by using the RJ11
cable with an adpatator RJ11 to SATA. The RJ11 to SATA adaptator is
sold separately.
SATA
Phone set connected over IP and PoE
Connected to the DC power jack of the desk phone by using DC Japan
cable.
Connected to the power supply of the device.
Connected to the SATA connector of the desk phone, by using the RJ11
cable with an adpatator RJ11 to SATA. The RJ11 to SATA adaptator is
sold separately.
SATA
