9Ver. 1.01
■ Review info for:
End User Account Name - the customer the Rock is intended for.
Site Name - number of sites and how many to install at each site.
Record the Rock Operational Mode to configure on-site (ex. 1FA, 1FAF, 2FA, mask).
– 6 Additional
■ 2-gang switch box (refer to Rock Install Guide for orientation)
■ 22/6 cable, 5-9 conductor, Genesis 12061109 or equivalent (Wiegand)
■ 4 conductor shielded twisted pair, Belden 3107A or equivalent (OSDP)
■ Shielded cat5e or higher cable
– 1 Required for Installation and not provided in box. Installer must provide:
■ Level
■ Measuring tape
■ Wire stripper / cutter
■ Phillips screwdriver
■ Gel filled connectors or wire nuts
– 2 Tools – additional tools may be needed
■ The network port and associated policy is configured for PoE+ (802.3at Type 2)
■ If the network port is not PoE+ then a PoE+ injector must be provided (802.3at Type 2)
■ The Ethernet cable from the PoE+ network port to the Rock is cat5e or higher, must be in
good condition, and shorter than 100m.
■ A PoE+ tester to confirm that at least 30W can be provided over the ethernet cable. (Confirms
that PoE+ (802.3at Type 2) is properly configured on the network port and that the ethernet
cable is good quality.)
■ Note that for UL294B installations, a UL294B certified injector is required.
– 3 PoE+ (802.3at Type 2) 30W Requirements
■ Customers have a wide range of network configuration requirements within their organization.
The on-prem installation is currently a white glove process.
■ Generate QR code for use to config Rock network settings using on-prem server
– 4 Network Requirements
■ Admin Portal: Username and Password (URL: https://login.alcatraz.ai/)
■ Request Asset Panda login credentials from Alcatraz if uploading images
■ Request a badge with access granted so you can test the Rock and tethered reader after
installation
– 5 CredentialsOn-Premise Pre-installation Requirements
The Alcatraz On-Premise solution includes a server appliance in addition to Rock quantity.
Pre-installation requirements for on-premise differ only in Network Requirements.
The On-Premise solution is currently a white glove process. Please contact Sales for more information.
