wish to rack-mount the unit using the rack ears included on the BRC.
The figure below indicates the rack ears' locations and the screws that
mount the end blocks. The front and back end blocks each use three
1" hexagonal screws, while the side end blocks use two 1-1/4"
hexagonal screws each. If you should ever wish to remount the end
blocks, it is important to note each screw’s original location when
they are removed since the screw lengths vary between the side end
blocks and the front and back end blocks. Do not substitute any of the
screws provided with the BRC, since their lengths are critical to their
specific locations.
Figure 3
2.10 ROLLAROUND STAND
The BRC may be mounted onto the optional rollaround stand. This
may be done using the four 1/2" hexagonal screws provided with the
stand. Be sure not to tighten these screws too much, as they can
physically damage the BRC. Please refer to the installation
instructions provided with the rollaround stand for more detailed
information.
