26
previous state, and the record ready buttons will be functional again.
3.2F All Clear
This switch is used to place all available tracks into a safe (non-record
ready) mode with a single button press. It differs from the ALL SAFE
button, in that it just clears all record ready tracks and does not disable
track record ready buttons; nor does it return to the previous state
when pressed again.
3.2G Groups 1 Through 4
The SET GROUP switch is used to assign a group of record enabled
tracks to a single button. Press and hold this button while pressing
one of the four GROUP buttons (1–4) you wish to store the current
track record status into. The GROUP button you select will have its
LED lit and the display will temporarily read:
Group X Stored
…where X is a number between 1 and 4.
The four GROUP buttons (1–4) are used to recall a configuration of
track record/inputs. When one of the group buttons is pressed by
itself, its LED will light (any other lit GROUP LED will be turned off)
and the stored record and input status will be recalled. If you now
press a record-enable button, the group LED will turn off to indicate
that the current status does not reflect a stored group’s record/input
configuration.
As a safety feature, you can disable the four GROUP buttons so that
their stored track record/inputs are not recalled (see section 5.3E).
This is in case you do not use the group function that much, and
have a tendency to push buttons very quickly and accidentally press
one of the GROUP buttons. If the GROUP buttons are disabled and
one of them is pressed, the display will briefly read:
Group Buttons
Disabled
The four GROUP buttons are always disabled while in record mode.
3.3 TRANSPORT CONTROLS
