Alesis Trigger iO User Manual

25
KIT#3 – CHROMATIC 1
INPUT
1 2 3 4 5 6 7 8 9 10
CHANNEL
1 1 1 1 1 1 1 1 1 1
TIP
MIDI NOTE # 60 62 64 66 68 70 72 74 76 78
CHANNEL
1 1 1 1 1 1 1 1 1 1
ZONE
RING
MIDI NOTE #
61 63 65 67 69 71 73 75 77 79
HI HAT FOOT SWITCH – CHANNEL 1, MIDI NOTE # 35
(INPUT3) CLOSED HI HAT NOTE # 42
KIT#4 – CHROMATIC 2
INPUT
1 2 3 4 5 6 7 8 9 10
CHANNEL
1 1 1 1 1 1 1 1 1 1
TIP
MIDI NOTE # 48 50 52 54 56 58 60 62 64 66
CHANNEL
1 1 1 1 1 1 1 1 1 1
ZONE
RING
MIDI NOTE #
49 51 53 55 57 59 61 63 65 67
HI HAT FOOT SWITCH – CHANNEL 1, MIDI NOTE # 35
(INPUT3) CLOSED HI HAT NOTE # 42
TRIGGER IO DEFAULT GLOBAL PARAMETERS
The following are the factory default global parameters for the Trigger IO:
INPUTS 1-10 HI HAT INPUT
GAIN 20 20
VEL CURVE Lin Lin
THRESHOLD 4 15
X-TALK 1 10
RETRIGGER 10 40
TRIGGER TYPE PP HH
