Alfa Laval ALF-R User Manual

Alfa Laval Copenhagen A/S APPENDIX B
ALF Instruction Manual UM_Filter_100B03 Page 44 of 67
PB 5: Diverter
Valve Open
LED 5 (g)
PB: Manual open diverter
valve
LED: Show open diverter
valve
While opening in both
manual and auto mode
While open in both
manual and auto mode
While closed or closing in
both manual and auto
mode
PB 6: Diverter
Valve Close
LED 6 (g)
PB: Manual close diverter
valve
LED: Show close diverter
valve
While closing in both
manual and auto mode
While closed in both
manual and auto mode
• While opened or
opening in both
manual and auto
mode
• Stand still
PB 7: Flush
Valve Open
LED 7 (g)
PB: Manual open flush
valve
LED: Show open flush
valve
While opening in both
manual and auto mode
• While open in both
manual and auto mode
• While diverter valve
closing and closed in
both manual and auto
mode
• While closed or
closing in both manual
and auto mode
• Stand still
PB 8: Flush
Valve Close
LED 8 (g)
PB: Manual close flush
valve
LED: Show close flush
valve
While closing in both
manual and auto mode
Stand still
While opening and
opened and while
diverter valve closing
and closed in both
manual and auto mode
PB 9-19:
Numeric
buttons and
point button
Used for numeric input - - -
PB 20:
“Escape”
button
Used for scrolling
between
menu pages, and jumping
up from submenus
- - -
PB 21: Enter
button
Used to confirm selected
or changed option
- - -
PB 22: Up
button
Used to cycle up between
menus or choice
selections
- - -
PB: 23: Down
button
Used to cycle down
between menus or choice
selections
- - -
PB 24: Info
button
Displays additional info for
screens where info id
available.
- - -
For more detailed information about Operator interface pages, please refer to APPENDIX C
User Passwords
On delivery, user password is 0000 (= no password), and service password = AL password. The
user password corresponds to protection level 1, and the service password corresponds to
protection level 2. Protection level 0 means that no password is required.
Access to resp. protection level is given when the operator enters the right password using
procedure 1 Login. The password is then valid for 20 minutes, or until procedure 2 Logout is used.
The current AL password is 1361. Could also be 1362, 1363, 1364, 1365, if necessary to be
changed.
