8138 SIP Multicolor Strobe Light
Features
SIP Paging: One 8138
The 8138 SIP Strobe Light can be registered as a third-party SIP extension with a hosted
or enterprise Communications Server supporting 3
rd
party SIP endpoints.
To register the strobe with the SIP server, use the Basic Settings > SIP tab in the web
interface to enter the Communication Server IP address, extension, username, and
password. This information will be available from the IT Administrator.
If VLAN is used, navigate to the Advanced Settings > Network tab to set VLAN options.
Important: once the strobe is using VLAN you will need to be on the same VLAN to
access the web interface.
The strobe may now be accessed by dialing its assigned extension from a telephone,
device, or client. The strobe will auto-answer and flash a light pattern.
There are a number of configurable strobe options:
• Flash Pattern
• Brightness
• Color 1
• Color 2
SIP Ring Event
Set Monitoring Mode to ‘Monitor Ring’ and enter credentials. When a call is made to the
SIP extension the 8138 will flash the selected light pattern. Often, the 8138 will be part of
a hunt group or ring group to flash in conjunction with a telephone.
Multicast Overview
In addition to the ring and page features, the 8138 is able to both send and receive IP
multicast messages over the network to support larger deployment for both paging and
ring/notification. This provides a scalable and efficient method of building large scale
notification solutions.
An Algo 8138 can be configured as a Master endpoint. When the SIP Page extension is
dialed from a phone, the 8138 will auto-answer, and flash a light pattern in chosen color.
Simultaneously, the registered 8138 endpoint broadcasts the audio over the network
using RTP multicast to any number/combination of Algo IP speakers, paging adapters,
and strobes as required.
The Slave endpoints require a PoE network connection but do not require registration to
the communication server.
Document 90-00102C
11/27/2019
Page 12
