8138 SIP Multicolor Strobe Light
1203 Call Switch
The 1203 Call Switch is a simple contact closure switch with an illuminated
button and supervision capabilities. When used in conjunction with the 8138,
the 1203 can prompt a single action with one-touch, or a continuous action if
the button is held.
1202 Call Button
The 1202 Call Button is a one-touch button for event notification and
response. It can be used with the 8138 for improved customer service,
emergency notification, and non-emergency alerting. The Call Button’s one-
touch button can trigger a flash pattern action, which can be halted via the
small cancel/reset button located below the main call button.
Action when Input Triggered
The relay input may be used to trigger the 8138 SIP Strobe Light only while the input is
active.
Action When Tamper Detected (Supervision)
In addition to the main events, the device can be configured with supervision to also
execute a strobe action in case the device goes offline due to wiring failure or after being
tampered with. The supervision configuration options will appear once a relay option with
supervision is selected. See the Electrical Specification section for details on supervision
detection circuit.
Output Relay
Enable or disable the output relay.
