32
APPENDIX A: SPECIFICATIONS
System Requirements
Operating System Microsoft® Windows® XP SP1 and above version / Vista / Win 7 / Server 2003 / Server 2008 32 bits
CPU Intel® Pentium IV 3.0 GHz or higher
RAM 1G or higher
Display 1024 × 768 resolution or higher
Web Browser Microsoft® Internet Explorer® 8.0 and above version, Apple Safari 5.02 and above version,
Client GUI
Client Alibi Central Management Software (ACMS) version 3.1 or later
General
Power Supply 12 Vdc, PoE+
Power Consumption Max.: 18 W (IR light 5 W Max.)
Working Temperature /
Humidity
Outdoor: -22°F to 149°F (-30°C to 65°C)
Humidity: ≤ 90%
Protection Level
IP66 standard (outdoor dome)
TVS 4,000 V lightning protection, surge protection and voltage transient protection
Dimensions Φ 6.65” × 6.34” Φ (169 mm × 161 mm )
Weight Approx. 5.40 lb (2.45 kg)
Accessories
ALI-AF10 F Wall Mount Bracket with Flange Adapter
ALI-AJ10 Junction Box
ALI-RM10 Recessed Mounting Adapter
