1ALI-NS8014VR IP PTZ Camera Installation and Setup Guide
SECTION 1: OVERVIEW
SECTION 1
Overview
Congratulations on purchasing your new ALIBI™ IP PTZ ultra low light camera! This installation guide includes procedures for
installing and performing the initial setup of the camera.
Special features of this camera include:
• Up to 4 MP (2560 × 1440) resolution
• Very low light minimum illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
• 25× optical zoom, 16× digital zoom
• 120 dB WDR, 3D DNR, HLC, BLC
• Up to 160 ft (50 m) IR distance
• 12 Vdc and PoE+ powering
• Supports H.265+ / H.265 video compression
Dome cover
Base
assembly
Dome screw
cover (4)
Mounting surface,
and adapter plate
Lens
Alarm IN
terminals
Alarm OUT
terminals
12 Vdc Power
Ground wire
Ethernet RJ45
(with PoE)
Audio IN/OUT
terminals
Drop cables
