12
Version 1.01
Parts name and functions
Right side of the tool
1 DB25 Connector
To connect the cables supplied with the tool. Refer to the Operating Manuals dedicated to the various protocols
available in the K-Suite software to know which cable to connect to the type of ECU on which you want to work.
Left side of the tool
1 Status LEDs
The red LED (top) lights up when the tool is connected to the computer through the USB cable. The green LED
(bottom) lights up when the tool is communicating with the ECU.
2 USB port
To connect the tool to the computer.
