Removing the M.2 2230 solid-state drive
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the
base cover.
About this task
NOTE: The following procedure applies only to computers shipped with an M.2 2230 solid-state drive.
NOTE: The M.2 card supported on this slot depends on the configuration ordered. Supported card configurations. Supported
card configurations:
● M.2 2230 solid-state drive + 2230 mounting bracket
● M.2 2280 solid-state drive
The following image(s) indicate the location of the M.2 2230 solid-state drive and provides a visual representation of the removal
procedure.
23
