illuminate. Two user LED lights are connected to the MIO of the PS, one is
connected to the IO of the PL, the user can control the lighting and off by the
program, when the IO voltage connected to the user LED light is high, the user
LED light is off, when the connection IO voltage is low, the user LED will be
illuminated. The schematic diagram of the LED light hardware connection is shown
in Figure 8-1:
Figure 8-1: The schematic diagram of the LED light hardware connection
Figure 8-2: LED light on the Core Board
