ZYNQ FPGA Development Platform AC7015 User Manual
Amazon Store: https://www.amazon.com/alinx
Sales Email: rachel.zhou@aithtech.com
Figure 6-5: GTP Reference Clock
Figure 6-6: 125Mhz oscillator on the Core Board
GTP Clock pin assignment:
Part 7: USB to Serial Port
For the AC7015 core board to work and debug separately, we have a Uart to
USB interface for the core board. Used for separate power supply and debugging
of the core board. The conversion chip uses the USB-UART chip of Silicon Labs
