ZYNQ FPGA Development Platform AC7015 User Manual
Amazon Store: https://www.amazon.com/alinx
Sales Email: rachel.zhou@aithtech.com
73
B34_L10_P
L2
74
-
-
75
-
-
76
-
-
77
B34_IO25
R8
78
B34_L7_P
J5
79
B34_IO0
H8
80
B34_L7_N
K5
Table 2-14-3: Pin Assignment of CON3
CON4 Pin
Signal Name
ZYNQ Pin
Name
CON4 Pin
Signal Name
ZYNQ Pin
Name
1
B13_L22_N
U18
2
B13_L20_P
U19
3
B13_L22_P
U17
4
B13_L20_N
V19
5
B13_L23_P
V16
6
B13_L19_N
T17
7
B13_L23_N
W16
8
B13_L19_P
R17
9
GND
-
10
GND
-
11
B13_L14_N
AA17
12
B13_L18_N
AA20
13
B13_L14_P
AA16
14
B13_L18_P
AA19
15
B13_L13_N
Y19
16
B13_L15_N
AB22
17
B13_L13_P
Y18
18
B13_L15_P
AB21
19
GND
-
20
GND
-
21
B13_L11_N
AA15
22
B13_L21_P
V18
23
B13_L11_P
AA14
24
B13_L21_N
W18
25
B13_L17_P
AB16
26
B13_L24_P
W17
27
B13_L17_N
AB17
28
B13_L24_N
Y17
29
GND
-
30
GND
-
31
B13_L16_N
AB19
32
B13_L2_P
V15
33
B13_L16_P
AB18
34
B13_L2_N
W15
35
B34_L22_P
M4
36
B13_L9_N
AB14
37
B34_L22_N
M3
38
B13_L9_P
AB13
39
GND
-
40
GND
-
41
B13_L12_N
Y15
42
B13_L6_N
U14
43
B13_IO25
U16
44
B13_L6_P
U13
45
B34_L6_P
M8
46
B34_L23_P
R5
47
B34_L6_N
M7
48
B34_L23_N
R4
