ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
23 / 29
Amazon Store: https://www.amazon.com/alinx
4
GND
-
-
Ground
5
MIPI1_LAN1_N
IO_L3N_64
AC8
MIPI Data 1 Signal N
6
MIPI1_LAN1_P
IO_L3P_64
AB8
MIPI Data 1 Signal P
7
GND
-
-
Ground
8
MIPI1_CLK_N
IO_L1N_64
AD9
MIPI Clock Signal N
9
MIPI1_CLK_P
IO_L1P_64
AC9
MIPI Clock Signal P
10
GND
-
-
Ground
11
CAM1_GPIO
IO_L2N_24
AH14
Control Signal IO
12
CAM1_CLK
IO_L3P_24
AG13
Control Signal Clock
13
CAM1_SCL
IO_L3N_24
AH13
Control Signal SCL
14
CAM1_SDA
IO_L4P_24
AE13
Control Signal SDA
15
VCC_3V3
-
-
3.3V Power Supply
MIPI Interface J24 Pin Assignment
PIN
Signal Name
ZYNQ Pin Name
ZYNQ Pin
Number
Description
1
GND
-
-
Ground
2
MIPI2_LAN0_N
IO_L2N_65
V9
MIPI Data 0 Signal N
3
MIPI2_LAN0_P
IO_L2P_65
U9
MIPI Data 0 Signal P
4
GND
-
-
Ground
5
MIPI2_LAN1_N
IO_L3N_65
V8
MIPI Data 1 Signal N
6
MIPI2_LAN1_P
IO_L3P_65
U8
MIPI Data 1 Signal P
7
GND
-
-
Ground
8
MIPI2_CLK_N
IO_L1N_65
Y8
MIPI Clock Signal N
9
MIPI2_CLK_P
IO_L1P_65
W8
MIPI Clock Signal P
10
GND
-
-
Ground
11
CAM2_GPIO
IO_L5P_24
AD15
Control Signal IO
12
CAM2_CLK
IO_L6P_24
AC14
Control Signal Clock
13
CAM2_SCL
IO_L5N_24
AD14
Control Signal SCL
14
CAM2_SDA
IO_L6N_24
AC13
Control Signal SDA
15
VCC_3V3
-
-
3.3V Power Supply
