ALLEN & HEATH iLIVE User Manual

iLive Fixed Format Getting Started Guide 36 AP7141 iss.6b
Inputs Dimensionsand Weights
XLRMic/LineInputs BalancedXLR,+48Vpha ntompower ModulariLive Wi dthxDepthxHeight
Mic/LinePreamp Fullyreca l l abl e iDR10MixRack9U 482x350x 400mm(19"x13.8"x15.8")26kg(57lb s)
I n putSensitivity ‐65to+15dBu i DR0MixRack2U 482x310x 88mm(19"x12.2"x3.5")7.3kg(16lbs )
AnalogueGain +10to+65dB,1dBsteps iLi ve‐112Surface 1006x
707x353mm(39.6"x27.7"x13.9")43kg(95lbs)
Pad ‐25dB iLive‐14 4Surface 1206x707x353mm(47.5"x27.7"x13.9")48kg(10 6lbs)
MaximumI nputLevel +32dBu iLive‐17 6Surface 1406x707x353mm(55.4"x27.7"x13.9")54kg(11 9lbs)
I n putI mpedanc e >4kΩ(Pad out),>10kΩ(Pad in) iPS10BackupPSU2U 482x310x 88mm(19"x12.2"x
3.5")7kg(15lbs)
MicEIN ‐127dBwith150Ωsource
FixedFormatiLive Wi dthxDepthxHeight
TRSLineInputs Balanced1/4"TRSjack(TandRSeries) iDR‐16MixRack3U 482x300x 132mm(19"x11.8"x5.2")7.5kg(16.5lbs)
I n putSensitivity Nominal+4dBu iDR‐32MixRack6 U 482x250x265mm(19"x10"x10.4")
12kg(26.4lbs)
Tri m +/‐24dB,recallable iDR‐48MixRack8U 482x250x353 mm(19 "x10"x13.9")16kg(35.2lbs)
MaximumI nputLevel +22dBu i DR‐64MixRack9U 482x250 x399mm(19"x10"x15.7")17.5kg(38 .5lbs)
I n putI mpedanc e >6 kΩ iLive‐R72‐WithSidetrims 472x540x237mm(18.6"x21.3"x9.3")12kg(26.5lbs )
iLive‐T80 770x635x
280mm(30.2"x11"x9.3")20kg(44lbs )
RCALineInputs UnbalancedRCAphono(TandRSeri es) iLi ve‐T112 1083x635x280mm(42.6"x11"x9.3 ")27kg(59 .4lbs)
I n putSensitivity Nominal0dBu xDR‐16Expa nderRack3U 482x300x 132mm(19"x11.8"x5.2")7kg(15.4lbs)
Tri m +/‐24dB,recallable
MaximumI nputLevel +18dBu
I n putI mpedanc e
>10kΩ
Control
DigitalInputs SRConea chpair.Upto96 kHzsamplingrate Faders 100mmmotori s ed,upto44faders
SPDIF 2ChRCA,600mV,coaxtermi na tedinput75Ω FaderBan ks I ndependentbankswi th4layerseach
AES(modular) 2ChXLR,2.5Vppbala ncedtermi nated110Ω ControlStrips From72to176dependingonSurfacesize
Opti ca l (modular) 2ChToslink TouchScreen 8.4"
TFT,800x6 00res ol ution
DigitalAudi oClockIn BNC(modulariLive) StripDisplay LCDperstrip,7assignabl ebacklightcol ours
SoftKeys 8assignablekeys
Outputs
ControlNetwork TCP/IPEthernet,built‐in3‐portswitch
MIDI Availabl eatMi xRackandSurface
XLROutputs Balanced,Relaypr otected PL‐Anet AtMixRackandSurface(modular),MixRackonly(Fixed)
OutputImpedance <75Ω Gangi ng Upto8gangswithupto8cha nnelseach
Nomi na l O utput +4dBu=0dBmeterreading DCAGroups 16configura bleasDCAorMuteGroups
MaximumOutput
Level  +22dBu
ResidualOutputNoi se
‐93dBu(muted,20‐20kHz)
Processing
TRSLineOutputs Balanced,Relayprotected(TandRSeries) Inputs HPF,Gate,PEQ,Compressor,Li m/De‐Es ser,Delay
OutputImpedance <75Ω
Nomi na l O utput +4dBu=0dBmeterreading Mixes PEQ,GEQ,Compressor,Li mi ter,Delay
MaximumOutputLevel +22dBu
ResidualOutputNoi se‐93dBu(muted,20‐20kHz) InternalFX 8xRackFXengi ne
Types Reverbs ,Delays,Modul ators,Sub‐harmonic s,SpeakerMtx
RCALineOutputs
Unbalanced,Relaypr o tected Dynamic‐EQ,MultibandCompressor
OutputImpedance <75Ω Mode Send>Return,Inserted,Dai syChainFX,directtooutput
Nomi na l O utput 0dBu=0dBmeterreadi ng
MaximumOutputLevel +18dBu FX'Short'ReturnChannels
ResidualOutputNoi se‐95dBu(muted,20‐20kHz) 8Stereodedicatedreturns Addstoinputsforupto72sourcestothemi x
FXReturnPEQ Same
asInputChan nelPEQ
DigitalOutputs 48kHzsamplingrate DynamicFX DFXduc kingandgatingshaper
SPDIF 2ChRCA,600mV,coaxtermi na tedinput75Ω
AES(option) 2Ch XLR,2.5Vppba lancedtermi nated110Ω Talkback Ass i gnabl esource
Opti ca l (modular) 2ChToslink HighPa ssFilter 12dB/octave,20Hz‐400Hz
DigitalAudi oClockOut BNC(modulariLive,MADI) Routing ToGroups,Aux,Mai n,Matri x
SignalGenerator Sine ,
WhiteNoise,PinkNoi s e,BandpassNoi se
System
Sine,Bandp as ssweep 20‐20kHz
Controls Level,Mute
MeasuredbalancedXLRintoXLRout,20‐20kHz,mini mumGain,Padout Routing ToGroups ,Aux,Mai n,Matri x
DynamicRange 112dB
SystemSignaltoNoi s e ‐90dB RTA 31‐Bands1/3octave20‐20kHz
Frequen cyResponse 20Hz‐20kHz+0/‐0.5dB Source Foll ows selectedPAFLsource
THD+N(analogueintoout) 0.0015%@+1 6dBuoutput,1kHz0dB
gain PeakBandIndica ti on Optiontodisplaydomi nantfrequenc y
Headroom +18dB
InternaloperatingLevel 0dBu
dBFSAlignment +18dBu=0dBFS(+22dBuatXLRoutput)
Memori es
MeterCal i brati on 0dBmeter=‐18dBFS(+4dBuatXLRout)
MeterPeakindication ‐3dBFS(+19d Bu atXLRout) Librar ies Forproc essing,FX,wholechannel .USBtrans fer
MeterType Fast(peak)res pons e Scenes 250‐Storeallor sel ectedparameters ,RecallSafes
SamplingRate 48kHz+/‐10 0PPM Shows Archi veal lsettings,Scenes Li brari es .USBtrans fer
ADC 24‐bitDelta‐Sigm a UserProfiles 8‐Admi nand7users
‐Pa sswords,permissions
DAC 24‐bitDelta ‐Sigma
Latency <2ms (MixRackXLRintoXLRout)
ACElinkis100us (0 .1 ms)perhop
iLiveConcept
OperatingTe mperatureRange 0degCto35 degC(3 2degFto95degF)
MixRack TherackistheDSPmi xer.Ca nbeusedwithouttheSurfac e
Surface TheSurfaceisacontrollerwithremoteaudi oI/O
MainsPower
DigitalSna ke(modular) SingleCAT5ACE
TM
link,ES,DanteorMADIoptio n
DigitalSna ke(fixedformat) SingleCAT5ACE
TM
link
ModulariLive 100‐240VAC,47‐63Hz,320Wmax PortBdigitalI/Ooption 64 channelbi ‐directional audio
FixedformatiLive 100‐2 40VAC,47‐63Hz,160Wmax Sys temExpa nsion Dual‐Racklinkingfor128inputchannels

ALLEN & HEATH iLIVE Specifications

General

Type	Digital Mixer
Rack Options	MixRack is rack-mountable
Remote Control	Via network using iLive Editor software
Connectivity	Ethernet, MADI
Processing	DSP
Sampling Rate	96kHz
EQ	4-band parametric
Dynamics	Compressor, gate
Mix Rack	Yes
Word Clock	Yes
Dimensions	Varies by component
Weight	Varies by component
Effects	Multi-effects processor
Power Supply	Internal redundant power supply (MixRack)
