Note: Description includes Allen and Heath part number in brackets
PA-CP Aux FX issue 2
Designator Description Designator Description
C1 CAPACITOR ELECTROLYTIC 100uF 6.3V (AF2984) R47 RESISTOR METAL FILM SMD0805 470K 2% (AC2844)
C2 CAPACITOR ELECTROLYTIC 100uF 6.3V (AF2984) R48 RESISTOR CARBON SMD0805 15K 5% (AC3486)
C3 CAPACITOR CERAMIC SMD0805 22P (AF2992) R49 RESISTOR CARBON SMD0805 15K 5% (AC3486)
C4 CAPACITOR CERAMIC SMD0805 22P (AF2992) R50 RESISTOR CARBON SMD0805 15K 5% (AC3486)
C5 CAPACITOR CERAMIC SMD0805 22P (AF2992) R51 RESISTOR CARBON SMD0805 15K 5% (AC3486)
C6 CAPACITOR CERAMIC SMD0805 22P (AF2992) R52 RESISTOR CARBON SMD0805 5K6 5% (AC4106)
C7 CAPACITOR CERAMIC SMD0805 22P (AF2992) R53 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
C8 CAPACITOR CERAMIC SMD0805 22P (AF2992) R54 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
C9 CAPACITOR CERAMIC SMD0805 22P (AF2992) R55 RESISTOR CARBON SMD0805 0R0 5% (AC2838)
C10 CAPACITOR CERAMIC SMD0805 22P (AF2992) R56 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C11 CAPACITOR CERAMIC SMD0805 22P (AF2992) R57 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C12 CAPACITOR CERAMIC SMD0805 22P (AF2992) R58 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C13 CAPACITOR CERAMIC SMD0805 22P (AF2992) R59 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C14 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R60 RESISTOR METAL FILM SMD0805 3K3 1% (AC3061)
C15 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R61 RESISTOR METAL FILM SMD0805 3K3 1% (AC3061)
C16 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R62 RESISTOR METAL FILM SMD0805 6K8 1% (AC3064)
C17 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R63 RESISTOR METAL FILM SMD0805 6K8 1% (AC3064)
C18 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) SW1 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
C19 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) SW2 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
C20 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) SW3 SWITCH 2 POLE MOMENTARY (AL0374)
C21 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) U1 IC SMD DUAL OP-AMP TL072 (AE3335)
C22 CAPACITOR CERAMIC SMD0805 100N (AF2851) U2 IC SMD DUAL OP-AMP TL072 (AE3335)
C23 CAPACITOR CERAMIC SMD0805 100N (AF2851) U3 IC SMD DUAL OP-AMP TL072 (AE3335)
C24 CAPACITOR CERAMIC SMD0805 100N (AF2851) U4 IC SMD DUAL OP-AMP TL072 (AE3335)
C25 CAPACITOR CERAMIC SMD0805 100N (AF2851) U5 IC SMD DUAL OP-AMP TL072 (AE3335)
C26 CAPACITOR CERAMIC SMD0805 47N (AF4889) U6 IC SMD DUAL OP-AMP TL072 (AE3335)
C27 CAPACITOR CERAMIC SMD0805 47N (AF4889) U7 IC SMD DUAL OP-AMP TL072 (AE3335)
C28 CAPACITOR CERAMIC SMD0805 47N (AF4889) VR1 POT ALPS 11mm 200KC X2 DUAL GANG 204C (AI8005)
C29 CAPACITOR CERAMIC SMD0805 47N (AF4889) VR2 POT ALPS 11mm 20KB C/D 203B (AI8004
)
CN1 RCA PHONO DUAL HORIZONTAL R/W (AL0577) VR3 POT ALPS 11mm 200KC X2 DUAL GANG 204C (AI8005)
CN2 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713) VR4 POT ALPS 11mm 20KB C/D 203B (AI8004
)
CN3 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713) VR5 POT ALPS 14mm 20KK x2 203K (AI8007
)
CN5 Connector IDC,Molex Type 0.1 Pitch 8x2 pins (AL4335) VR7 POT ALPS 11mm 20KK 203K (AI8003
)
CN6 Connector IDC,Molex Type 0.1 Pitch 8x2 pins (AL4335) VR8 POT ALPS 11mm 20KK 203K (AI8003
)
CN7 EARTH SCREW TERMINAL NARROW HORIZONTAL TYPE (AA9000)
CN8 EARTH SCREW TERMINAL NARROW HORIZONTAL TYPE (AA9000)
CN9 EARTH SCREW TERMINAL NARROW HORIZONTAL TYPE (AA9000)
D1 DIODE SIGNAL SMD BAS16 (AE3352)
LD1 LED RECT 5x2.5MM TOMBSTONE RED (AE4863
)
LD2 LED T1 3mm RED (AE0086
)
Q1 TRANSISTOR JFET N CHANNEL J111N (AE0083)
Q2 TRANSISTOR JFET N CHANNEL J111N (AE0083)
Q3 TRANSISTOR NPN BC549 (AE0020)
R1 RESISTOR METAL FILM SMD0805 100K 1% (AC2843)
R2 RESISTOR METAL FILM SMD0805 100K 1% (AC2843)
R3 RESISTOR METAL FILM SMD0805 100K 1% (AC2843)
R4 RESISTOR METAL FILM SMD0805 20K 1% (AC5057)
R5 RESISTOR SMD 20K 1% 0805 (AC5057)
R6 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R7 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R8 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R9 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R10 RESISTOR METAL FILM SMD0805 22K 1% (AC2842)
R11 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R12 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R13 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R14 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R15 RESISTOR METAL FILM SMD0805 22K 1% (AC2842)
R16 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R17 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R19 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R20 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R21 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
R22 RESISTOR METAL FILM SMD0805 6K8 1% (AC3064)
R23 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R24 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R25 RESISTOR METAL FILM SMD0805 22K 1% (AC2842)
R26 RESISTOR METAL FILM SMD0805 22K 1% (AC2842)
R27 RESISTOR METAL FILM SMD0805 22K 1% (AC2842)
R28 RESISTOR METAL FILM SMD0805 22K 1% (AC2842)
R29 RESISTOR METAL FILM SMD0805 22K 1% (AC2842)
R30 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R31 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R32 RESISTOR CARBON SMD0805 12K 5% (AC4107)
R33 RESISTOR CARBON SMD0805 12K 5% (AC4107)
R34 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R35 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R36 RESISTOR CARBON SMD0805 47K 5% (AC3035)
R37 RESISTOR CARBON SMD0805 47K 5% (AC3035)
R38 RESISTOR CARBON SMD0805 47K 5% (AC3035)
R39 RESISTOR CARBON SMD0805 47K 5% (AC3035)
R40 RESISTOR CARBON SMD0805 47K 5% (AC3035)
R41 RESISTOR CARBON SMD0805 22K 5% (AC3540)
R42 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R43 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R44 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R45 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R46 RESISTOR METAL FILM SMD0805 3K3 1% (AC3061)
Page 1 of 1
003−036
