ALLEN & HEATH PA Series Service Information

Note: Description includes Allen and Heath part number in brackets
PA-CP Linear PSU issue 3
Designator Description Designator Description
BR1 BRIDGE RECTIFIER 35A 600V BRSB356G (AE0239) P9 BLADE TERMINAL 1/4" (AL0392)
BR2 BRIDGE RECTIFIER 2KB6PM (AE3477) P10 BLADE TERMINAL 1/4" (AL0392)
BR3 BRIDGE RECTIFIER 2KB6PM (AE3477) P11 BLADE TERMINAL 1/4" (AL0392)
C1 CAPACITOR ELECTROLYTIC 1MF 63V RADIAL (AF0210) P12 BLADE TERMINAL 1/4" (AL0392)
C9 CAPACITOR ML CERAMIC 100NF 100V (AF2689) P13 BLADE TERMINAL 1/4" (AL0392)
C10 CAPACITOR ML CERAMIC 100NF 100V (AF2689) P14 BLADE TERMINAL 1/4" (AL0392)
C11 CAPACITOR ML CERAMIC 100NF 100V (AF2689) P15 BLADE TERMINAL 1/4" (AL0392)
C12 CAPACITOR ML CERAMIC 100NF 100V (AF2689) P16 BLADE TERMINAL 1/4" (AL0392)
C13 CAPACITOR ML CERAMIC 100NF 100V (AF2689) P17 BLADE TERMINAL 1/4" (AL0392)
C14 CAPACITOR ELECT 4700MF 125V (AF5101) P18 BLADE TERMINAL 1/4" (AL0392)
C15 CAPACITOR ELECT 4700MF 125V (AF5101) P19 BLADE TERMINAL 1/4" (AL0392)
C16 CAPACITOR ELECT 4700MF 125V (AF5101) P20 BLADE TERMINAL 1/4" (AL0392)
C17 CAPACITOR ELECT 4700MF 125V (AF5101) P21 BLADE TERMINAL 1/4" (AL0392)
C18 CAPACITOR MULTILAYER CERAMIC 100NF 100V (AF2689) Q1 TRANSISTOR BC549 NPN (AE0020)
C19 CAPACITOR ELECTROLYTIC 47uF 63V (AF0217) Q2 TRANSISTOR BC549 NPN (AE0020)
C20 CAPACITOR ELECTROLYTIC 10MF 50V RADIAL (AF0214) Q3 TRANSISTOR BC549 NPN (AE0020)
C21 CAPACITOR ELECT 220MF 10V RADIAL (AF0225) R1 RESISTOR WIREWOUND 10R 3W (AC4839)
C22 CAPACITOR ELECT 2200MF 35V RADIAL (AF8145) R2 RESISTOR CARBON 10K 1/4W 5% (AC0046)
C23 CAPACITOR ELECT 2200MF 35V RADIAL (AF8145) R3 RESISTOR ZERO OHM (AC0335)
C24 CAPACITOR ELECTROLYTIC 10,000MF 16V RAD (AF3051) R4 RESISTOR ZERO OHM (AC0335)
CN1 Connector IDC,Molex Type 0.1" Pitch 8x2 pins (AL0562) R5 RESISTOR CARBON 1K 1/4W 5% (AC0031)
CN3 MAINS INLET IEC FILTER PCB 3 PIN 10A (AL5118) R6 RESISTOR CARBON 10K 1/4W 5% (AC0046)
D1 DIODE RECTIFIER 1N4002 (AE0005) R7 RESISTOR CARBON 47K 1/4W 5% (AC0057)
D2 DIODE RECTIFIER 1N4002 (AE0005) R8 RESISTOR CARBON 47K 1/4W 5% (AC0057)
D3 DIODE RECTIFIER 1N4002 (AE0005) R9 RESISTOR CARBON 27K 1/4W 5% (AC0053)
D4 DIODE SIGNAL 1N4148 (AE0007) R10 RESISTOR CARBON 15K 1/4W 5% (AC0048)
D5 DIODE RECTIFIER 1N4002 (AE0005) R11 RESISTOR CARBON 180R 5% (AC0015)
D6 DIODE RECTIFIER 1N4002 (AE0005) R12 RESISTOR CARBON 12K 1/4W 5% (AC0047)
EARTH 1 BLADE TERMINAL 1/4" (AL0392) R13 RESISTOR CARBON 100K 1/4W 5% (AC0064)
EARTH 2 BLADE TERMINAL 1/4" (AL0392) R14 RESISTOR CARBON 100K 1/4W 5% (AC0064)
F1 FUSE COVER SCHURTER (AL8139) R15 RESISTOR CARBON 100K 1/4W 5% (AC0064)
F1 FUSE 20MM 16A 250V A/SURGE (AL8154) R16 RESISTOR CARBON 100K 1/4W 5% (AC0064)
Manufacturer: Schurte
r
Part number: 0034.3129
R17 RESISTOR CARBON 100K 1/4W 5% (AC0064)
F2 FUSE COVER SCHURTER (AL8139) R18 RESISTOR CARBON 100K 1/4W 5% (AC0064)
F2 FUSE 20MM 16A 250V A/SURGE (AL8154) R19 RESISTOR CARBON 100K 1/4W 5% (AC0064)
Manufacturer: Schurte
r
Part number: 0034.3129
R20 RESISTOR CARBON 100K 1/4W 5% (AC0064)
F3 FUSE COVER SCHURTER (AL8139) RLY1 RELAY G2RL-1 OMRON (AM5053)
F3 FUSE 20MM 1A A/SURGE (AL0305) RLY2 RELAY G2RL-1 OMRON (AM5053)
F4 FUSE COVER SCHURTER (AL8139) RLY3 RELAY G2RL-1 OMRON (AM5053)
F4 FUSE 20MM 1A A/SURGE (AL0305) SW1 SW DPST SOLTEAM MAINS PS3-22-P3AV (AL3338)
F5 FUSE COVER SCHURTER (AL8139) SW2 SWITCH ALPHA SW2PCO SLIDE (AL5071)
F5 FUSE 20MM 1.6A/250V A/SURGE (AL0466) U1 TL783 VOLTAGE REGULATOR (AE0214)
F6 FUSE HOLDER 20mm (AL3178
)
U2 IC REGULATOR 7815 (AE0047)
F6 FUSE 20MM 10A 250V A/SURGE (AL3455) U3 IC REGULATOR 7915 (AE0048)
Manufacturer: Schurte
r
Part number: 0034.3127
INSUL KIT T0220 SELF ADHESIVE (AA3514)
F1A FUSE CLIP SCHURTER (AL8134) HEATSINK PA LINEAR PSU (AA4991
)
F1B FUSE CLIP SCHURTER (AL8134) HEATSINK PA SERIES LINEAR BRIDGE (AA5097
)
F2A FUSE CLIP SCHURTER (AL8134)
F2B FUSE CLIP SCHURTER (AL8134)
F3A FUSE CLIP SCHURTER (AL8134)
F3B FUSE CLIP SCHURTER (AL8134)
F4A FUSE CLIP SCHURTER (AL8134)
F4B FUSE CLIP SCHURTER (AL8134)
F5A FUSE CLIP SCHURTER (AL8134)
F5B FUSE CLIP SCHURTER (AL8134)
LK1 TC WIRE LINK (AH0070)
LK2 TC WIRE LINK (AH0070)
LK3 TC WIRE LINK (AH0070)
LK4 TC WIRE LINK (AH0070)
LK5 TC WIRE LINK (AH0070)
LK6 TC WIRE LINK (AH0070)
LK7 TC WIRE LINK (AH0070)
LK8 TC WIRE LINK (AH0070)
LK9 TC WIRE LINK (AH0070)
LK10 TC WIRE LINK (AH0070)
LK11 TC WIRE LINK (AH0070)
LK12 TC WIRE LINK (AH0070)
LK13 TC WIRE LINK (AH0070)
LK14 TC WIRE LINK (AH0070)
LK15 TC WIRE LINK (AH0070)
LK16 TC WIRE LINK (AH0070)
LK17 TC WIRE LINK (AH0070)
LK18 TC WIRE LINK (AH0070)
LK19 TC WIRE LINK (AH0070)
LK20 TC WIRE LINK (AH0070)
LK21 TC WIRE LINK (AH0070)
LK22 TC WIRE LINK (AH0070)
LK23 TC WIRE LINK (AH0070)
LK24 TC WIRE LINK (AH0070)
NTC1 INRUSH SUPPRESSOR NTC 10R (AE8143)
P1 BLADE TERMINAL 1/4" (AL0392)
P2 BLADE TERMINAL 1/4" (AL0392)
P3 BLADE TERMINAL 1/4" (AL0392)
P4 BLADE TERMINAL 1/4" (AL0392)
P5 BLADE TERMINAL 1/4" (AL0392)
P6 BLADE TERMINAL 1/4" (AL0392)
P7 BLADE TERMINAL 1/4" (AL0392)
P8 BLADE TERMINAL 1/4" (AL0392)
Page 1 of 1
003−069
