ALLEN & HEATH PA Series Service Information

Kernick Industrial Estate,
Penryn, Cornwall,
England. TR10 9LU
+44 (0)8707 556250
+44 (0)8707 556251
2
PA SERIES LED PCB
C5054 1 1
PAGE:
TITLE:
DRG No: ISSUE: SHEET: OF
ISSUE BY DATE
FILE: C5054_2.Sch 13:16:45 27-Mar-2003
ALLEN&HEATH
Tel:
Fax:
PRINTED:
ABCDEFGH
a
b
c
d
e
1
2
3
4
5
6
7
8
9
10
11
12
CN1
FLEX SKT 12 WAY 90 DEG
LED_1
LED_2
LED_3
LED_4
LED_5
LED_6
LED_7
LED_8
BANK_LED
+5V
DG
R1
680R 1% 0805
LD1
LED RECT 5X2.5MM TOMB GRN
LD4
LED RECT 5X2.5MM TOMB GRN
R2
680R 1% 0805
LD2
LED RECT 5X2.5MM TOMB GRN
LD5
LED RECT 5X2.5MM TOMB GRN
R3
680R 1% 0805
LD3
LED RECT 5X2.5MM TOMB GRN
LD6
LED RECT 5X2.5MM TOMB GRN
R4
680R 1% 0805
LD7
LED RECT 5X2.5MM TOMB GRN
LD11
LED RECT 5X2.5MM TOMB GRN
R5
680R 1% 0805
LD8
LED RECT 5X2.5MM TOMB GRN
LD12
LED RECT 5X2.5MM TOMB GRN
R6
680R 1% 0805
LD9
LED RECT 5X2.5MM TOMB GRN
LD13
LED RECT 5X2.5MM TOMB GRN
R7
680R 1% 0805
LD10
LED RECT 5X2.5MM TOMB GRN
LD14
LED RECT 5X2.5MM TOMB GRN
R8
680R 1% 0805
LD15
LED RECT 5X2.5MM TOMB GRN
LD16
LED RECT 5X2.5MM TOMB GRN
Q3
BC848B
Q2
BC848B
Q1
BC848B
R9
10K 1% 0805
R10
10K 1% 0805
R11
10K 1% 0805
R12
10K 1% 0805
+5V
DG
BANK_LED
LED_1
LED_2
LED_3
LED_4
LED_5
LED_6
LED_7
LED_8
A AAT 04-07-02
FH1
HOLE-FIXING 3.5MM
FH2
HOLE-FIXING 3.5MM
FH3
HOLE-FIXING 3.5MM
FH4
HOLE-FIXING 3.5MM
1 AAT 06-08-02
C1
100N 0805
DG
2 AAT 24-09-02
SCREW1
SCREW M3X4 PAN TORX BK
SCREW2
SCREW M3X4 PAN TORX BK
PILLAR1
PILLAR M3X6 HEX BRASS
PILLAR2
PILLAR M3X6 HEX BRASS
