ALLEN & HEATH PA Series Service Information

Note: Description includes Allen and Heath part number in brackets
PA-CP FX LED issue 2
Designator Description
CN1 FLEX SKT 12 WAY 90 DEG (AL2226)
LD1 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD2 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD3 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD4 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD5 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD6 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD7 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD8 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD9 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD10 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD11 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD12 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD13 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD14 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD15 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
LD16 LED RECTANGULAR 5 X 2.5 TOMBSTONE GREEN (AE4864)
Q1 TRANSISTOR NPN BC848B (AE3332)
Q2 TRANSISTOR NPN BC848B (AE3332)
Q3 TRANSISTOR NPN BC848B (AE3332)
R1 RESISTOR SMD 680R 1% 0805 (AC3058)
R2 RESISTOR SMD 680R 1% 0805 (AC3058)
R3 RESISTOR SMD 680R 1% 0805 (AC3058)
R4 RESISTOR SMD 680R 1% 0805 (AC3058)
R5 RESISTOR SMD 680R 1% 0805 (AC3058)
R6 RESISTOR SMD 680R 1% 0805 (AC3058)
R7 RESISTOR SMD 680R 1% 0805 (AC3058)
R8 RESISTOR SMD 680R 1% 0805 (AC3058)
R9 RESISTOR SMD 10K 1% 0805 (AC2841)
R10 RESISTOR SMD 10K 1% 0805 (AC2841)
R11 RESISTOR SMD 10K 1% 0805 (AC2841)
R12 RESISTOR SMD 10K 1% 0805 (AC2841)
Page 1 of 1
003−070
