ALLEN & HEATH PA Series Service Information

Note: Description includes Allen and Heath part number in brackets
PA-CP L/R Master issue 3
Designator Description Designator Description
C1 CAPACITOR ELECTROLYTIC 100MF 25V RADIAL (AF0221) R39 RESISTOR CARBON SMD0805 0R0 5% (AC2838)
C2 CAPACITOR ELECTROLYTIC 100MF 25V RADIAL (AF0221) R40 RESISTOR CARBON SMD0805 0R0 5% (AC2838)
C3 CAPACITOR CERAMIC SMD0805 22P (AF2992) R41 RESISTOR CARBON SMD0805 0R0 5% (AC2838)
C4 CAPACITOR CERAMIC SMD0805 22P (AF2992) R42 RESISTOR CARBON SMD0805 0R0 5% (AC2838)
C5 CAPACITOR CERAMIC SMD0805 22P (AF2992) R43 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C6 CAPACITOR CERAMIC SMD0805 22P (AF2992) R44 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C7 CAPACITOR CERAMIC SMD0805 22P (AF2992) R45 RESISTOR METAL FILM SMD0805 470K 2% (AC2844)
C8 CAPACITOR CERAMIC SMD0805 22P (AF2992) R46 RESISTOR CARBON SMD0805 68R 5% (AC4101)
C9 CAPACITOR CERAMIC SMD0805 22P (AF2992) R47 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
C10 CAPACITOR CERAMIC SMD0805 22P (AF2992) R48 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
C11 CAPACITOR CERAMIC SMD0805 22P (AF2992) R49 RESISTOR CARBON SMD0805 68R 5% (AC4101)
C12 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R50 RESISTOR CARBON SMD0805 68R 5% (AC4101)
C13 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R51 RESISTOR CARBON SMD0805 68R 5% (AC4101)
C14 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R52 RESISTOR CARBON SMD0805 68R 5% (AC4101)
C15 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R53 RESISTOR CARBON SMD0805 68R 5% (AC4101)
C16 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R54 RESISTOR METAL FILM SMD0805 33R 1% (AC2839)
C17 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R55 RESISTOR CARBON SMD0805 10R 5% (AC3027)
C19 CAPACITOR CERAMIC SMD0805 100N (AF2851) R58 RESISTOR CARBON SMD0805 10R 5% (AC3027)
C20 CAPACITOR CERAMIC SMD0805 100N (AF2851) R59 RESISTOR CARBON SMD0805 10R 5% (AC3027)
C21 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) SW1 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
C22 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) SW2 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
C23 CAPACITOR CERAMIC SMD0805 100N (AF2851) SW3 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
C24 CAPACITOR CERAMIC SMD0805 100N (AF2851) SW4 SWITCH DPDT ALPS (SPUJ) LATCHING (AL8065)
C25 CAPACITOR CERAMIC SMD0805 100N (AF2851) SW5 SWITCH DPDT ALPS (SPUJ) LATCHING (AL8065)
C26 CAPACITOR CERAMIC SMD0805 100N (AF2851) SW6 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
C27 CAPACITOR SMD 150 NF 25V CERAMIC 0805 (AF4888) SW7 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
C28 CAPACITOR SMD 330 NF CERAMIC 0805 (AF5070) U1 IC SMD NE5532 OP AMP (AE4699)
CN1 JACK SKT 1/4" ST PCB METAL (AL4713) U2 IC SMD DUAL OP-AMP TL072 (AE3335)
CN2 JACK SKT 1/4" ST PCB METAL (AL4713) U3 IC SMD DUAL OP-AMP TL072 (AE3335)
CN3 JACK SKT 1/4" ST PCB METAL (AL4713) U4 IC SMD DUAL OP-AMP TL072 (AE3335)
CN4 JACK SKT 1/4" ST PCB METAL (AL4713) U5 IC SMD DUAL OP-AMP TL072 (AE3335)
CN5 Connector IDC,Molex Type 0.1 Pitch 8x2 pins (AL4335) U6 IC SMD LM393 (AE5068)
CN6 BOX HEADER 0.1" 26 WAY 90 DEG (AL3592) U7 IC SMD DUAL OP-AMP TL072 (AE3335)
CN7 Connector IDC,Molex Type 0.1 Pitch 8x2 pins (AL4335) VR1 POT ALPS 11mm 20KK 203K (AI8003
)
CN8 EARTH SCREW TERMINAL NARROW HORIZONTAL TYPE (AA9000) VR2 POT ALPS 11mm 20KK 203K (AI8003
)
D1 DIODE SIGNAL SMD BAS16 (AE3352) VR3 POT ALPS 11mm 20KK 203K (AI8003
)
D2 DIODE SIGNAL SMD BAS16 (AE3352) VR4 POT ALPS 14mm 20KK x2 203K (AI8007
)
LD1 LED T1 3mm RED (AE0086
)
LD2 LED T1 3mm GREEN (AE0085
)
LD3 LED T1 3mm YELLOW (AE0084)
LD4 LED T1 3mm YELLOW (AE0084)
LD5 LED T1 3mm YELLOW (AE0084)
LD6 LED T1 3mm GREEN (AE0085
)
LD7 LED T1 3mm RED (AE0086
)
LD8 LED T1 3mm BLUE (AE4041
)
LD9 LED RECTANGULAR RED 5 X 2.5 MM TOMBSTONE (AE4863)
LD10 LED RECTANGULAR GREEN 5 X 2.5 MM TOMBSTONE (AE4864
)
LD11 LED RECTANGULAR RED 5 X 2.5 MM TOMBSTONE (AE4863)
Q1 TRANSISTOR JFET N CHANNEL J111N (AE0083)
Q2 TRANSISTOR JFET N CHANNEL J111N (AE0083)
R1 RESISTOR METAL FILM SMD0805 100K 1% (AC2843)
R2 RESISTOR METAL FILM SMD0805 100K 1% (AC2843)
R3 RESISTOR METAL FILM SMD0805 100K 1% (AC2843)
R4 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R5 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R6 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R7 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R8 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R9 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R10 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R11 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R12 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R13 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R14 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R15 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R16 RESISTOR METAL FILM SMD0805 33K 1% (AC3532)
R17 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R18 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R19 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R20 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R21 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R22 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R23 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R24 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R25 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R26 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R27 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R28 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R29 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R30 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R31 RESISTOR SMD 5K6 5% 0805 (AC4106)
R32 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
R33 RESISTOR SMD 6K8 1% 0805 (AC3064)
R34 RESISTOR SMD 5K6 5% 0805 (AC4106)
R35 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
R36 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
R37 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
R38 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
Page 1 of 1
003−040
