ALLEN & HEATH PA Series Service Information

Note: Description includes Allen and Heath part number in brackets
PA-CP Distribution issue 2
Designator Description
CN1 Connector IDC,Molex Type 0.1 Pitch 8x2 pins Female Straight (AL3868)
CN2 Connector IDC,Molex Type 0.1 Pitch 8x2 pins Female Straight (AL3868)
CN3 Connector IDC,Molex Type 0.1 Pitch 8x2 pins Female Straight (AL3868)
CN4 Connector IDC,Molex Type 0.1 Pitch 8x2 pins Female Straight (AL3868)
CN5 Connector IDC,Molex Type 0.1 Pitch 8x2 pins Female Straight (AL3868)
CN6 Connector IDC,Molex Type 0.1 Pitch 13x2 PINS FEMALE STRAIGHT (AL5045)
JP1 TC WIRE LINK (AH0070)
JP2 TC WIRE LINK (AH0070)
JP3 TC WIRE LINK (AH0070)
JP4 TC WIRE LINK (AH0070)
JP5 TC WIRE LINK (AH0070)
LK1 TC WIRE LINK (AH0070)
LK2 TC WIRE LINK (AH0070)
LK3 TC WIRE LINK (AH0070)
LK4 TC WIRE LINK (AH0070)
LK5 TC WIRE LINK (AH0070)
LK6 TC WIRE LINK (AH0070)
LK7 TC WIRE LINK (AH0070)
LK8 TC WIRE LINK (AH0070)
LK9 TC WIRE LINK (AH0070)
LK10 TC WIRE LINK (AH0070)
LK11 TC WIRE LINK (AH0070)
LK12 TC WIRE LINK (AH0070)
LK13 TC WIRE LINK (AH0070)
LK14 TC WIRE LINK (AH0070)
LK15 TC WIRE LINK (AH0070)
LK16 TC WIRE LINK (AH0070)
LK17 TC WIRE LINK (AH0070)
LK18 TC WIRE LINK (AH0070)
LK19 TC WIRE LINK (AH0070)
LK20 TC WIRE LINK (AH0070)
LK21 TC WIRE LINK (AH0070)
LK22 TC WIRE LINK (AH0070)
LK23 TC WIRE LINK (AH0070)
LK24 TC WIRE LINK (AH0070)
LK25 TC WIRE LINK (AH0070)
LK26 TC WIRE LINK (AH0070)
LK27 TC WIRE LINK (AH0070)
R1 RESISTOR WIRE WOUND 4R7 2.5W (AC4779)
Page 1 of 1
003−041
