ALLEN & HEATH PA Series Service Information

Note: Description includes Allen and Heath part number in brackets
PA-CP Sub 1 issue 1
Designator Description
C1 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208)
C2 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208)
C3 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208)
C4 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208)
C5 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208)
C6 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208)
C7 CAPACITOR CERAMIC SMD0805 22P (AF2992)
C8 CAPACITOR CERAMIC SMD0805 22P (AF2992)
C9 CAPACITOR SMD 6N8 CERAMIC 0805 (AF2994)
C10 CAPACITOR SMD 6N8 CERAMIC 0805 (AF2994)
C11 CAPACITOR SMD 6N8 CERAMIC 0805 (AF2994)
C12 CAPACITOR SMD 6N8 CERAMIC 0805 (AF2994)
C13 CAPACITOR CERAMIC SMD0805 100N (AF2851)
C14 CAPACITOR CERAMIC SMD0805 100N (AF2851)
CN1 RCA PHONO DUAL HORIZONTAL R/W (AL0577)
CN2 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713)
CN3 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713)
CN4 Connector IDC,Molex Type 0.1 Pitch 8x2 pins (AL4335)
LD(S)1 LED BAR MB12 SQUARE LEDS IN HOUSING 8G,3Y,1R (AE2701)
Q(S)1 TRANSISTOR PNP BC858B (AE3042)
R1 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R2 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R3 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R4 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R5 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R6 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R7 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R8 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R9 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R10 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R11 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R12 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R13 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R14 RESISTOR CARBON SMD0805 12K 5% (AC4107)
R15 RESISTOR CARBON SMD0805 12K 5% (AC4107)
R16 RESISTOR CARBON SMD0805 12K 5% (AC4107)
R17 RESISTOR CARBON SMD0805 12K 5% (AC4107)
R18 RESISTOR CARBON SMD0805 15K 5% (AC3486)
R19 RESISTOR CARBON SMD0805 15K 5% (AC3486)
R20 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R21 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R22 RESISTOR CARBON SMD0805 2K7 5% (AC4698)
R23 RESISTOR CARBON SMD0805 2K7 5% (AC4698)
R24 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
R25 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
R(S)1 RESISTOR METAL FILM SMD0805 1K2 1% (AC3059)
R(S)2 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
R(S)3 RESISTOR CARBON SMD0805 15K 5% (AC3486)
R(S)4 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
R(S)5 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
R(S)6 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
R(S)7 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
R(S)8 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
R(S)9 RESISTOR METAL FILM SMD0805 330R 1% (AC3056)
R(S)10 RESISTOR METAL FILM SMD0805 330R 1% (AC3056)
R(S)11 RESISTOR METAL FILM SMD0805 560R 1% (AC3057)
R(S)12 RESISTOR METAL FILM SMD0805 680R 1% (AC3058)
R(S)13 RESISTOR METAL FILM SMD0805 1K2 1% (AC3059)
R(S)14 RESISTOR METAL FILM SMD0805 1K2 1% (AC3059)
R(S)15 RESISTOR CARBON SMD0805 3K9 5% (AC4105)
R(S)16 RESISTOR METAL FILM SMD0805 1K0 1% (AC0369)
U1 IC SMD DUAL OP-AMP TL072 (AE3335)
U2 IC SMD DUAL OP-AMP TL072 (AE3335)
U(S)1 IC LM339 COMPARATOR SMD (AE4890)
U(S)2 IC LM339 COMPARATOR SMD (AE4890)
U(S)3 IC LM339 COMPARATOR SMD (AE4890)
VR1 POT ALPS 11mm 200KC X2 DUAL GANG 204C (AI8005)
VR2 POT ALPS 11mm 20KB C/D 203B (AI8004
)
VR3 POT ALPS 11mm 200KC X2 DUAL GANG 204C (AI8005)
VR4 POT ALPS 11mm 20KB C/D 203B (AI8004
)
Page 1 of 1
003−037
