Note: Description includes Allen and Heath part number in brackets
PA-CP Amplifier issue 4
Designator Description Designator Description Designator Description
C1 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) LK21 TC LINK (AH0070) R23 RESISTOR METAL 10K 0.6W 1% (AC5121)
C2 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) LK22 TC LINK (AH0070) R24 RESISTOR METAL 10K 0.6W 1% (AC5121)
C3 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) LK23 TC LINK (AH0070) R25 RESISTOR CARBON 27K 1/4W 5% (AC0053)
C4 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) LK24 TC LINK (AH0070) R26 RESISTOR CARBON 27K 1/4W 5% (AC0053)
C5 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) LK25 TC LINK (AH0070) R29 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
C6 CAPACITOR DISK 10 PF 200V (AF5076) LK26 TC LINK (AH0070) R30 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
C7 CAPACITOR MULTILAYER CERAMIC 100NF 100V (AF2689) LK27 TC LINK (AH0070) R31 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
C8 CAPACITOR POLYESTER 100NF 63V 10% (AF0571) LK28 TC LINK (AH0070) R32 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
C9 CAPACITOR MULTILAYER CERAMIC 100NF 100V (AF2689) LK29 TC LINK (AH0070) R33 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
C10 CAPACITOR MULTILAYER CERAMIC 100NF 100V (AF2689) LK30 TC LINK (AH0070) R34 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
C11 CAPACITOR DISK 22PF 200V (AF5074) LK31 TC LINK (AH0070) R35 RESISTOR METAL FILM 2R7 2.5W 5% (AC5073)
C12 CAPACITOR DISK 22PF 200V (AF5074) LK32 TC LINK (AH0070) R36 RESISTOR METAL FILM 2R7 2.5W 5% (AC5073)
C13 CAPACITOR DISK CERAMIC 220PF 100V (AF8163) LK33 TC LINK (AH0070) R37 RESISTOR WIRE WOUND 0R15 3W (AC5122)
C14 CAPACITOR DISK CERAMIC 220PF 100V (AF8163) LK34 TC LINK (AH0070) R38 RESISTOR WIRE WOUND 0R15 3W (AC5122)
C15 CAPACITOR DISK 22PF 200V (AF5074) LK35 TC LINK (AH0070) R39 RESISTOR WIRE WOUND 0R15 3W (AC5122)
C16 CAPACITOR DISK 22PF 200V (AF5074) LK36 TC LINK (AH0070) R40 RESISTOR WIRE WOUND 0R15 3W (AC5122)
C19 CAPACITOR ELECTROLYTIC 330uF 10V (AF2288) LK37 TC LINK (AH0070) R41 RESISTOR WIRE WOUND 0R15 3W (AC5122)
C20 CAPACITOR MYLAR 1NF 100V 10% (AF0150) LK39 TC LINK (AH0070) R42 RESISTOR WIRE WOUND 0R15 3W (AC5122)
C21 CAPACITOR POLYESTER 100NF 63V 10% (AF0571) LK40 TC LINK (AH0070) R43 RESISTOR CARBON 68K 1/4W 5% (AC0062)
C22 CAPACITOR ELECTROLYTIC 1uF 63V (AF0210) LK41 TC LINK (AH0070) R44 RESISTOR CARBON 22K 1/4W 5% (AC0050)
C23 CAPACITOR ELECTROLYTIC 10uF 50V (AF0214) LK42 TC LINK (AH0070) R45 RESISTOR CARBON 22K 1/4W 5% (AC0050)
C24 CAPACITOR ELECTROLYTIC 10uF 50V (AF0214) LK43 TC LINK (AH0070) R46 RESISTOR CARBON 470R 1/4W 5% (AC0024)
C25 CAPACITOR MULTILAYER CERAMIC 100NF 100V (AF2689) LK44 TC LINK (AH0070) R47 RESISTOR CARBON 470R 1/4W 5% (AC0024)
C26 CAPACITOR MULTILAYER CERAMIC 100NF 100V (AF2689) LK45 TC LINK (AH0070) R48 RESISTOR CARBON 470R 1/4W 5% (AC0024)
C27 CAPACITOR ELECTROLYTIC 10uF 50V (AF0214) LK46 TC LINK (AH0070) R49 RESISTOR CARBON 220R 1/4W 5% (AC0018)
CN1 BOX HEADER 0.1" 16W STRAIGHT (AL0562) LK47 TC LINK (AH0070) R50 RESISTOR WIRE WOUND 3R3 3W 5% (AC2822)
D1 BZX79C12V 12V ZENER DIODE (AE0232) LK48 TC LINK (AH0070) R51 RESISTOR CARBON 1M0 1/4W 5% (AC0104)
D2 BZX79C12V 12V ZENER DIODE (AE0232) LK49 TC LINK (AH0070) R52 RESISTOR WIRE WOUND 4K7 2.5W 5% (AC5072)
D3 DIODE SIGNAL 1N4148 (AE0007) LK50 TC LINK (AH0070) R53 RESISTOR CARBON 0R0 1/4W 5% (AC0335)
D4 DIODE SIGNAL 1N4148 (AE0007) LK51 TC LINK (AH0070) R54 RESISTOR WIRE WOUND 47R 2.5W 5% (AC3527)
D5 DIODE SIGNAL 1N4148 (AE0007) LK52 TC LINK (AH0070) R55 RESISTOR CARBON 1K 1/4W 5% (AC0031)
D6 DIODE SIGNAL 1N4148 (AE0007) LK53 TC LINK (AH0070) R56 RESISTOR CARBON 6K8 1/4W 5% (AC0101)
D7 DIODE SIGNAL 1N4148 (AE0007) LK54 TC LINK (AH0070) R57 RESISTOR CARBON 4K7 1/4W 5% (AC0044)
D8 DIODE SIGNAL 1N4148 (AE0007) LK55 TC LINK (AH0070) R58 RESISTOR CARBON 470R 1/4W 5% (AC0024)
D9 DIODE SIGNAL 1N4148 (AE0007) LK56 TC LINK (AH0070) R59 RESISTOR CARBON 47K 1/4W 5% (AC0057)
D10 DIODE SIGNAL 1N4148 (AE0007) LK57 TC LINK (AH0070) R60 RESISTOR CARBON 150K 1/4W 5% (AC0068)
D11 DIODE SIGNAL 1N4148 (AE0007) LK58 TC LINK (AH0070) R61 RESISTOR CARBON 47K 1/4W 5% (AC0057)
D12 DIODE SIGNAL 1N4148 (AE0007) P1 1/4 INCH BLADE TERMINAL (AL0392) R62 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
D13 DIODE SIGNAL 1N4148 (AE0007) P2 1/4 INCH BLADE TERMINAL (AL0392) R63 RESISTOR CARBON XK 1/4W 5% (AC0091)
D14 DIODE SIGNAL 1N4148 (AE0007) P3 1/4 INCH BLADE TERMINAL (AL0392) R64 RESISTOR CARBON 8K2 1/4W 5% (AC0045)
D15 DIODE SIGNAL 1N4148 (AE0007) Q1 TRANSISTOR PNP MPSA92 (AE8119) R65 RESISTOR CARBON 10K 1/4W 5% (AC0046)
D16 DIODE SIGNAL 1N4148 (AE0007) Q2 TRANSISTOR PNP MPSA92 (AE8119) R66 RESISTOR CARBON 22K 1/4W 5% (AC0050)
D17 DIODE SIGNAL 1N4148 (AE0007) Q3 TRANSISTOR PNP MPSA92 (AE8119) R67 RESISTOR CARBON 33K 1/4W 5% (AC0054)
D18 DIODE SIGNAL 1N4148 (AE0007) Q4 TRANSISTOR PNP MPSA92 (AE8119) R68 RESISTOR CARBON 270R 1/4W 5% (AC0020)
D19 DIODE SIGNAL 1N4148 (AE0007) Q5 TRANSISTOR PNP MPSA92 (AE8119) R69 RESISTOR CARBON 270R 1/4W 5% (AC0020)
D20 DIODE SIGNAL 1N4148 (AE0007) Q6 TRANSISTOR NPN MPSA42 (AE8138) R70 RESISTOR CARBON 270R 1/4W 5% (AC0020)
D21 DIODE SIGNAL 1N4148 (AE0007) Q7 TRANSISTOR NPN MPSA42 (AE8138) R71 RESISTOR CARBON 100R 1/4W 5% (AC0008)
D22 DIODE SIGNAL 1N4148 (AE0007) Q8 TRANSISTOR NPN MPSA42 (AE8138) R72 RESISTOR CARBON 270K 1/4W 5% (AC0074)
D23 DIODE SIGNAL 1N4148 (AE0007) Q9 TRANSISTOR NPN MPSA42 (AE8138) R73 RESISTOR CARBON 0R0 1/4W 5% (AC0335)
D24 DIODE SIGNAL 1N4148 (AE0007) Q10 TRANSISTOR NPN MPSA42 (AE8138) R77 RESISTOR CARBON 1K0 1/4W 5% (AC0031)
D25 DIODE IN4007 1A 1000V (AE5075) Q11 TRANSISTOR NPN MPSA42 (AE8138) RLY1 RELAY SPNO 12V 30A (AM5128)
D26 DIODE IN4007 1A 1000V (AE5075) Q12 TRANSISTOR NPN MPSA42 (AE8138) RLY1 RELAY COVER (AM8141)
D27 DIODE SIGNAL 1N4148 (AE0007) Q13 TRANSISTOR NPN MPSA42 (AE8138) TH1 THERMISTOR 100K (AE3499)
D28 DIODE IN4007 1A 1000V (AE5075) Q14 TRANSISTOR NPN BC637 (AE0068) U1 IC TL071 OP-AMP (AE0045)
D29 DIODE SIGNAL 1N4148 (AE0007) Q15 TRANSISTOR NPN POWER MJE340 (AE8155) U2 IC TL072 OP-AMP (AE0046)
D30 DIODE SIGNAL 1N4148 (AE0007) Q16 TRANSISTOR MOSFET N CHANNEL ECX10N20 (AE4883) U3 OPTO COUPLER (LDR) NSL32 (AE4377)
F1 FUSE CLIP SHURTER (AL8134) Q17 TRANSISTOR 2SA1295 PNP POWER (AE5119) U4 IC LM339 COMPARATOR (AE0071)
F1 FUSE CLIP SHURTER (AL8134) Q18 TRANSISTOR 2SA1295 PNP POWER (AE5119) HEATSINK HEATSINK (AA4854)
F1 FUSE COVER SCHURTER (AL8139) Q19 TRANSISTOR 2SA1295 PNP POWER (AE5119) INSUL PAD TDA7294 IC SELF ADHESIVE (AA3645)
F1 FUSE 20 MM 10A 250V A/SURGE (AL3455) Q20 TRANSISTOR PNP POWER MJE350 (AE8156) FAN 60X60 12V (AM4959)
Manufacturer: Schurte
Part number: 0034.3127
Q26 TRANSISTOR NPN BC637 (AE0068)
JMP1 MOLEX 0.1" MALE 3 PIN STRAIGHT (AL0320) R1 RESISTOR CARBON 47R 1/4W 5% (AC0333)
JMP2 MOLEX 0.1" MALE 3 PIN STRAIGHT (AL0320) R2 RESISTOR WIRE WOUND 4K7 2.5W 5% (AC5072)
JMP3 MOLEX 0.1" MALE 3 PIN STRAIGHT (AL0320) R3 RESISTOR CARBON 100R 1/4W 5% (AC0008)
L1 INDUCTOR 5UH 10A WE-SD (AM4882) R4 RESISTOR CARBON 100R 1/4W 5% (AC0008)
LK1 TC LINK (AH0070) R5 RESISTOR CARBON 100R 1/4W 5% (AC0008)
LK2 TC LINK (AH0070) R6 RESISTOR CARBON 100R 1/4W 5% (AC0008)
LK3 TC LINK (AH0070) R7 RESISTOR CARBON 100K 1/4W 5% (AC0064)
LK4 TC LINK (AH0070) R8 RESISTOR CARBON 82K 1/4W 5% (AC0063)
LK5 TC LINK (AH0070) R9 RESISTOR CARBON 82K 1/4W 5% (AC0063)
LK6 TC LINK (AH0070) R10 RESISTOR CARBON 100K 1/4W 5% (AC0064)
LK7 TC LINK (AH0070) R11 RESISTOR CARBON 100K 1/4W 5% (AC0064)
LK8 TC LINK (AH0070) R12 RESISTOR CARBON 100K 1/4W 5% (AC0064)
LK9 TC LINK (AH0070) R13 RESISTOR CARBON 100K 1/4W 5% (AC0064)
LK10 TC LINK (AH0070) R14 RESISTOR CARBON 100K 1/4W 5% (AC0064)
LK11 TC LINK (AH0070) R15 RESISTOR CARBON 10K 1/4W 5% (AC0046)
LK12 TC LINK (AH0070) R16 RESISTOR CARBON 10K 1/4W 5% (AC0046)
LK13 TC LINK (AH0070) R17 RESISTOR CARBON 10K 1/4W 5% (AC0046)
LK14 TC LINK (AH0070) R18 RESISTOR CARBON 10K 1/4W 5% (AC0046)
LK15 TC LINK (AH0070) R19 RESISTOR CARBON 10K 1/4W 5% (AC0046)
LK16 TC LINK (AH0070) R20 RESISTOR METAL 1K2 1/4W 1% (AC0036)
LK18 TC LINK (AH0070) R21 RESISTOR CARBON 10K 1/4W 5% (AC0046)
LK19 TC LINK (AH0070) R22 RESISTOR CARBON 10K 1/4W 5% (AC0046)
Page 1 of 1
003−043
