ALLEN & HEATH PA Series Service Information

Note: Description includes Allen and Heath part number in brackets
PA-CP FB1 Phones issue 2
Designator Description Designator Description
C1 CAPACITOR CERAMIC SMD0805 22P (AF2992) R37 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C2 CAPACITOR SMD 1N5 CERAMIC SMD (AF2991
)
R38 RESISTOR SMD 22K 1% 0805 (AC2842)
C3 CAPACITOR SMD 1N5 CERAMIC SMD (AF2991
)
R39 RESISTOR SMD 22K 1% 0805 (AC2842)
C4 CAPACITOR CERAMIC SMD0805 22P (AF2992) R40 RESISTOR SMD 22K 1% 0805 (AC2842)
C5 CAPACITOR SMD 1N5 CERAMIC SMD (AF2991
)
R41 RESISTOR SMD 22K 1% 0805 (AC2842)
C6 CAPACITOR SMD 1N5 CERAMIC SMD (AF2991
)
R42 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C7 CAPACITOR ELECTROLYTIC 100uF 6.3V (AF2984) R43 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
C8 CAP SM 33pF (AF4887) R44 RESISTOR METAL FILM SMD0805 2K2 1% (AC0370)
C9 CAP SM 33pF (AF4887) R45 RESISTOR METAL FILM SMD0805 2K2 1% (AC0370)
C10 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R46 RESISTOR METAL FILM SMD0805 33R 1% (AC2839)
C11 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R47 RESISTOR METAL FILM SMD0805 33R 1% (AC2839)
C12 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R48 RESISTOR METAL FILM SMD0805 33R 1% (AC2839)
C13 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R49 RESISTOR CARBON SMD0805 22K 5% (AC3540)
C14 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R50 RESISTOR CARBON SMD0805 22K 5% (AC3540)
C15 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R51 RESISTOR METAL FILM SMD0805 33R 1% (AC2839)
C16 CAPACITOR CERAMIC SMD0805 100N (AF2851) R52 RESISTOR SMD 56K 1% 0805 METAL (AC5051)
C17 CAPACITOR CERAMIC SMD0805 100N (AF2851) R53 RESISTOR METAL FILM SMD0805 330K 1% (AC3087)
C18 CAPACITOR CERAMIC SMD0805 100N (AF2851) R54 RESISTOR CARBON SMD0805 1K8 5% (AC3029)
C19 CAPACITOR ELECTROLYTIC 100uF 6.3V (AF2984) R55 RESISTOR SMD 56K 1% 0805 METAL (AC5051)
C20 CAP SM 33pF (AF4887) R56 RESISTOR METAL FILM SMD0805 330K 1% (AC3087)
C21 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R57 RESISTOR CARBON SMD0805 1K8 5% (AC3029)
C22 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R58 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
C23 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R59 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
C24 CAP SM 33pF (AF4887) R60 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
C25 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R61 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
C26 CAP SM 33pF (AF4887) R62 RESISTOR METAL FILM SMD0805 120R 1% (AC3055)
C27 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R63 RESISTOR METAL FILM SMD0805 330R 1% (AC3056)
C28 CAPACITOR ELECTROLYTIC 1000uF 6.3V (AF8123) R64 RESISTOR METAL FILM SMD0805 330R 1% (AC3056)
C29 CAPACITOR ELECTROLYTIC 1000uF 6.3V (AF8123) R65 RESISTOR METAL FILM SMD0805 560R 1% (AC3057)
C30 CAPACITOR ELECTROLYTIC 1uF 63V (AF0210) R66 RESISTOR METAL FILM SMD0805 680R 1% (AC3058)
C31 CAPACITOR ELECTROLYTIC 1uF 63V (AF0210) R67 RESISTOR METAL FILM SMD0805 1K2 1% (AC3059)
C32 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R68 RESISTOR METAL FILM SMD0805 1K2 1% (AC3059)
C33 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R69 RESISTOR CARBON SMD0805 3K9 5% (AC4105)
C34 CAPACITOR ELECTROLYTIC 47uF 25V (AF0208) R70 RESISTOR METAL FILM SMD0805 1K0 1% (AC0369)
CN1 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713) R71 RESISTOR CARBON SMD0805 15K 5% (AC3486)
CN2 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713) R72 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
CN3 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713) R73 RESISTOR METAL FILM SMD0805 1K2 1% (AC3059)
CN4 JACK SOCKET HORIZONTAL 6 PIN MET HEADPHONE (AL4713) R74 RESISTOR CARBON SMD0805 47K 5% (AC3035)
CN5 Connector IDC,Molex Type 0.1 Pitch 8x2 pins (AL4335) R75 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
CN6 Connector IDC,Molex Type 0.1 Pitch 8x2 pins (AL4335) R76 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
CN7 EARTH SCREW TERMINAL NARROW HORIZONTAL TYPE (AA9000) R77 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
D1 DIODE SIGNAL SMD BAS16 (AE3352) R78 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
D2 DIODE SIGNAL SMD BAS16 (AE3352) R79 RESISTOR SMD 2K7 5% 0805 (AC4698)
D3 DIODE SIGNAL SMD BAS16 (AE3352) R80 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
D4 DIODE SIGNAL SMD BAS16 (AE3352) R81 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
D5 DIODE SIGNAL SMD BAS16 (AE3352) R82 RESISTOR CARBON SMD0805 15K 5% (AC3486)
LD1 LED 0.2" RED (AE0001) R85 RESISTOR SMD 0R 5% 0805 (AC2838)
LD3 LED T1 3MM RED (AE0086) R87 RESISTOR SMD 0R 5% 0805 (AC2838)
LD2 LED RECT 5x2.5MM TOMBSTONE RED (AE4863
)
SW1 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
LD4 LED BAR MB12 SQUARE LEDS IN HOUSING 8G,3Y,1R (AE2701) SW2 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
Q1 TRANSISTOR NPN BC848B (AE3332) SW3 SWITCH DPDT ALPS (SPUN) LATCHING (AL0162)
Q2 TRANSISTOR PNP BC858B (AE3042) U1 IC SMD 74HC4053 (AE3355)
R1 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) U2 IC SMD DUAL OP-AMP TL072 (AE3335)
R2 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) U3 IC SMD DUAL OP-AMP TL072 (AE3335)
R3 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) U4 IC SMD DUAL OP-AMP NE5532 (AE4699)
R4 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) U5 IC SMD DUAL OP-AMP NE5532 (AE4699)
R5 RESISTOR SMD 2K7 5% 0805 (AC4698) U6 IC SMD DUAL OP-AMP TL072 (AE3335)
R6 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) U7 IC LM339 COMPARATOR SMD (AE4890)
R7 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) U8 IC LM339 COMPARATOR SMD (AE4890)
R8 RESISTOR CARBON SMD0805 15K 5% (AC3486) U9 IC LM339 COMPARATOR SMD (AE4890)
R9 RESISTOR METAL FILM SMD0805 100K 1% (AC2843) U10 IC SMD DUAL OP-AMP TL072 (AE3335)
R10 RESISTOR SMD 27K 1% 0805 METAL (AC5049) U11 IC SMD DUAL OP-AMP TL072 (AE3335)
R11 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) U12 IC SMD DUAL OP-AMP TL072 (AE3335)
R12 RESISTOR METAL FILM SMD0805 10K 1% (AC2841) VR1 POT ALPS 11mm 200KC X2 DUAL GANG 204C (AI8005)
R13 RESISTOR SMD 47K 5% 0805 (AC3035) VR2 POT ALPS 11mm 20KB C/D 203B (AI8004
)
R14 RESISTOR SMD 47K 5% 0805 (AC3035) VR3 POT ALPS 11mm 200KC X2 DUAL GANG 204C (AI8005)
R15 RESISTOR SMD 15K 1% 0805 METAL (AC5050) VR4 POT ALPS 11mm 20KB C/D 203B (AI8004
)
R16 RESISTOR CARBON SMD0805 22K 5% (AC3540) VR5 POT ALPS 14mm 20KK x2 203K (AI8007
)
R17 RESISTOR METAL FILM SMD0805 6K8 1% (AC3064) modification CAP ML CER 100NF 100V 104
R18 RESISTOR CARBON SMD0805 22K 5% (AC3540)
R19 RESISTOR METAL FILM SMD0805 3K3 1% (AC3061)
R20 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R21 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R22 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R23 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R24 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R25 RESISTOR CARBON SMD0805 68R 5% (AC4101)
R26 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
R27 RESISTOR CARBON 10R PRE FORMED 1/4W 5% (AC5077)
R28 RESISTOR METAL FILM SMD0805 4K7 1% (AC3062)
R29 RES SMD 56K 1% 0805 METAL FILM (AC5051)
R30 RESISTOR CARBON SMD0805 220K 5% (AC4108)
R31 RESISTOR CARBON SMD0805 5K6 5% (AC4106)
R32 RESISTOR METAL FILM SMD0805 6K8 1% (AC3064)
R33 RESISTOR CARBON SMD0805 5K6 5% (AC4106)
R34 RESISTOR METAL FILM SMD0805 100K 1% (AC2843)
R35 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
R36 RESISTOR METAL FILM SMD0805 10K 1% (AC2841)
Page 1 of 1
003−038
