ALLEN & HEATH PA Series Service Information

pa_series_parts_4.doc Sheet 2 of 2
PA Series Surface Parts
HANDLE AA4922 FRONT EXTRUSION AA4923
M
3
x
5
SC
REW AB
53
44
SIDE MOULDIING AA4920-L/R
OR RACK EARS AA5013
1
JACK NUT AL4715
JACK SOCKET AL4713
M3x5 SCREW AB5344
LATCHING SWITCH
A
L0162
FEMALE XLR AL2412
4x5/16 SCREW
A
B2810
5WAY FEMALE DIN SOCKET
A
L3962
4
x
5/16 SCREW AB2810
SINGLE PHONO
A
L4895DUAL PHONO
A
L0577
SPEAKER OUTPUTS
4 OHM LOAD MINIMUM
500W + 500W RMS
CAUTION
RISK OF ELECTRIC SHOCK
8 OHMS4 OHMS
CONSTANT POW ER SWITCH
DO NOT OPEN
SERIAL NUMBER
FUSE
0
V AC ~ 47- 63 Hz
1600W MAX
MAINS INPUT
CAUTION: FOR CONTINUED PROT ECTION AGAINST R ISK OF FIRE
ATTENTION: REMPLAC ER LE FUSIBLE AVEC UN DES MEMES CARACTERISTIQUES.
SEE OPERATING MANUAL BEFORE USING.
NO USER SERVICEABLE PARTS INSIDE.
DO NOT OBSTRUCT VENTILATION OPENINGS.
RISK OF HAZARDOUS ENERGY! MAKE PROPER SPEAKER CONNECTIONS.
THIS APPARATUS MUST BE EARTHED BY THE POWER CORD.
DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK
100-240V T10A L
ENGINEERED IN ENGLAND BY ALLEN & HEATH Ltd.
SET SWITCH TO MATCH SPEAKER IMPEDANCE
REPLACE FUSE WITH SAME TYPE AND RATING.
12V LAMP
ON/OFF
I
CONNECT SPEAKER BETWEEN PIN 1+ AND PIN 1-
15DIA 9MM HIGH FAST FOOT
A
K5069M4x8 SCREW
A
B0332
BLACK BUTTON
A
J2887
MAINS SWITCH
A
L3338
MAINS IEC
A
L5118
M3
x
10 SCREW
A
B0076
20DIA P4x5 FAST FOOT
A
K0102
FUSE HOLDER
A
L3178
10A FUSE AL3455
SLIDE SWITCH
A
L5071 SPEAKON CONNECTOR AL8126
M3
x
6 SCREW
A
B0072
M3x10 SCREW
A
B0093
M3
x
10 SCREW
A
B0093 4PIN FEMALE XLR
A
L8104
MAINS IEC
A
L3458
MALE XLR AL2411 4x5/16 SCREW
A
B2810
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK
SEE OPERATING MANUAL BEFORE USING.
DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
THIS APPARATUS MUST BE EARTHED BY THE POWER CORD.
AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR.
RISK OF ELECTRIC SHOCK
ATTENTION: REMPLACER LE FUSIBLE AVEC UN DES MEMES CARACTERISTIQUES.
CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE
CAUTION
NO USER SERVICEABLE PARTS INSIDE.
DO NOT OPEN
100 - 240 V AC ~ 47- 63 Hz
100-240V T1A L
REPLACE FUSE WITH SAME TYPE AND RATING.
ON/OFF
I 0
75W MAX
FUSE
ENGINEERED IN ENGLAND BY ALLEN & HEATH Ltd.
SERIAL NUMBER
MAINS INPUT
BALANCED PIN2 = +
MAIN OUTPUT
PA series products up to serial
number 019388 have x1 stereo
MASTER LR FADER
PA series products from serial
number 019388 have x2 mono
MASTER L & R FADERS

ALLEN & HEATH PA Series Specifications

General

Type	Analog Mixer
Microphone Preamps	Yes
Phantom Power	Yes
Power Supply	Internal
EQ Bands per Channel	3
Subgroups	4
Dimensions (W x D x H)	Varies by model
Weight	Varies by model
