Quick Start for Experienced Users 2-7
11. Check that the module is operating correctly. Reference
During normal operation (PLC or SLC in Run mode), the 1747-ASB module appears as shown
below:
Chapter 6
(Start-Up and
Operation)
Chapter 7
(Troubleshooting)
ADAPTER
COMM FAULT
Green COMM
LED is on.
Red F AULT
LED is off.
Status display
indicates a
run
condition.
STATUS
