Chapter 7
Configure ControlLogix Digital I/O Modules
You must configure your module upon installation. The module will not work
until it has been configured. In most cases, you will use RSLogix 5000 software to
complete the configuration. The software uses default configurations, such as
RPI and filter times, to get your I/O module to communicate with its owner-
controller. You can edit the default configuration as needed from the Module
Properties dialog box.
Topic Page
Configuration Process Overview 128
Create a New Module 129
Edit the Configuration 134
Connection Properties 135
View and Change ModuleTags 136
