Chapter 7 Configure ControlLogix Digital I/O Modules
Configuration
Process Overview
Follow these steps to configure a ControlLogix digital I/O module with
RSLogix 5000 software.
1. Create a new module.
2. Accept or customize the default configuration for the module.
3. Edit the configuration as changes are needed.
Figure 20 - Full Configuration Profile Diagram
1. Choose a module
from the list.
2. Choose a Major
Revision.
Name
Slot number
Communication/
connection format
Minor revision
Keying choice
Series of
Application
Specific
Screens
Click a tab to customize the
configuration.
Click OK to use the default
configuration.
41058
New Module
Naming Screen
Tab s
OK Button
Configuration Complete
Edit Configuration
A series of tabs in RSLogix 5000 software
enable you to change a module’s
configuration.
