Chapter 8 Wiring Diagrams
1756-OV16E
ControlLogix DC (10...30V) electronically-fused, sinking output module
12
34
56
7
8
910
11
12
1314
1516
1718
19
20
+
–
Group 0Group 0
Group 1Group 1
DC COM
1756-OV16E
OUT-1
OUT-3
OUT-5
OUT-7
OUT-9
OUT-11
OUT-13
OUT-15
DC-0(+)
DC-1(+)
OUT-0
OUT-2
OUT-4
OUT-6
OUT-8
OUT-10
OUT-12
OUT-14
RTN OUT-0
RTN OUT-1
Daisy Chain to Other RTBs
Daisy Chain to Other RTB
ControlLogix
Backplane
Interface
Electronic Fuse
Circuitry
Continuous @ 60 °C (140 °C)
Display Optoisolation
RTN
OUT-0
OUT-0
DC-0(+)
Surge Current Chart
Simplified Schematic
Surge
Current
Time
010 ms
1 A
2 A
