Allen-Bradley 1756-IA32 - 1756-Iv32

152 Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
Chapter 8 Wiring Diagrams
1756-IV32
ControlLogix DC (10...30V) sourcing input module
12
34
56
78
910
1112
1314
1516
1718
1920
2122
2324
2526
2728
2930
3132
3334
3536
+
–
Daisy
Chain to
Other
RTBs
DC COM
0 puorG0 puorG
1 puorG1 puorG
1756-IV32
IN-1
IN-3
IN-5
IN-7
DC-0 (+)
IN-9
IN-11
IN-13
IN-15
DC-1 (+)
IN-17
IN-19
IN-21
IN-23
IN-25
IN-27
IN-29
IN-31
IN-0
IN-2
IN-4
IN-6
DC-0 (+)
IN-8
IN-10
IN-12
IN-14
DC-1 (+)
IN-16
IN-18
IN-20
IN-22
IN-24
IN-26
IN-28
IN-30
Jumper
Wire
ControlLogix
Backplane
Interface
Simplified Schematic
Display
IN-0
GND
DC-0+
+5V
