72 Rockwell Automation Publication 1756-RM093J-EN-P - April 2018
Appendix A Safety Instructions
Metal Form Safety
Application Instructions
These instructions are available in RSLogix 5000 software, version 17 and later.
SMAT Safety Mat Indicates whether or not the safety mat is occupied.
THRSe Two-Hand Run Station – Enhanced Monitors two diverse safety inputs, one from a right-hand push button and one from a left-hand
push button, to control a single output. Features configurable channel-to-channel discrepancy
time and enhanced capability for bypassing a two-hand run station.
TSAM Two Sensor Asymmetrical Muting Provides temporary, automatic disabling of the protective function of a light curtain, using two
muting sensors arranged asymmetrically.
TSSM Two Sensor Symmetrical Muting Provides temporary, automatic disabling of the protective function of a light curtain, using two
muting sensors arranged symmetrically.
FSBM Four Sensor Bidirectional Muting Provides temporary, automatic disabling of the protective function of a light curtain, using four
sensors arranged sequentially before and after the light curtain’s sensing field.
Table 12 - RSLogix 5000 Software, Version 17 and Later, Safety Application Instructions
Mnemonic Name Purpose
Mnemonic Name Purpose
CBCM Clutch Brake Continuous Mode Used for press applications where continuous operation is desired.
CBIM Clutch Brake Inch Mode Used for press applications where minor slide adjustments are required, such as press setup.
CBSSM Clutch Brake Single Stoke Mode Used in single-cycle press applications.
CPM Crankshaft Position Monitor Used to determine the slide position of the press.
CSM Camshaft Monitor Monitors motion for the starting, stopping, and running operations of a camshaft.
EPMS Eight-position Mode Selector
Monitors eight safety inputs to control one of the eight outputs corresponding to the active input.
AVC Auxiliary Valve Control Controls an auxiliary valve that is used in conjunction with a main valve.
MVC Main Valve Control Controls and monitors a main valve.
MMVC Maintenance Manual Valve
Control
Used to manually drive a valve during maintenance operations.
