12 Rockwell Automation Publication 1756-RM012B-EN-P - April 2018
Chapter 1 Safety Integrity Level (SIL) Concept
Figure 2 - Example SIL 2 System
5069-OBV8S
COUNTER
5069-HSC2xOB4
SIL2 CPU
5069-L3100ERMS2
Compact GuardLogix
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
5069-IB8S
OUTPUT
5069-OBV8S
COUNTER
5069-HSC2xOB4
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
5069-IB8S
OUTPUT
Compact I/O™
Actuator
Sensor
5069-AEN2TR
Compact 5000 I/O Modules
Compact 5000 I/O Safety Modules
Compact GuardLogix 5380 Controller
Compact 5000 I/O Modules
Compact 5000 I/O Safety Modules
HMI Display
Stratix 5400 Switch
Programming Software
To plant-wide Ethernet Network
Safety System
