Page #13 background image
1769-L32E, 1769-L35E CompactLogix Controller 13
Publication
1769-IN020-C-EN-P - July 2007
Panel Mounting
Mount the controller to a panel by using two screws per module. Use
M4 or #8 panhead screws. Mounting screws are required on every
module.
This procedure lets you use the assembled modules as a template for
dril
ling holes in the panel.
1. On
a clean work surface, assemble no more than three
modules.
2. Usin
g the assembled modules as a template, carefully mark the
center of all module-mounting holes on the panel.
3. Retu
rn the assembled modules to the clean work surface,
including any previously mounted modules.
4. Dril
l and tap the mounting holes for the recommended M4 or
#8 screw.
5. Plac
e the modules back on the panel and check for proper
hole alignment.
IMPORTANT
Due to module mounting hole tolerance, it is important to follow these procedures.
TIP
The grounding plate, located where the you install the mounting screws, enables the
module to be grounded when it is panel-mounted.
