32 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020-C-EN-P - July 2007
OK Off No power is applied.
Flashing red If the controller is new, the controller requires a firmware update.
If the controller is not new, a major fault occurred.
To clear the fault, do one of the following:
•T
urn the keyswitch from Prog to Run to Prog.
•Go online with RSLogix 5000 software.
Solid red The controller detected a nonrecoverable fault, so it cleared the
p
roject from memory. Follow these steps to recover.
1. Cycle power to the chassis.
2. Download the project.
3. Change to Run mode.
If the OK status indicator remains solid red, contact your
Ro
ckwell Automation representative or local distributor.
Solid green Controller is OK.
Flashing green The controller is storing or loading a project to or from
n
onvolatile memory.
Indicator Status Description
