1769-L32E, 1769-L35E CompactLogix Controller 37
Publication
1769-IN020-C-EN-P - July 2007
Environmental Specifications
Attribute Value
Operational temperature
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0...60 °C (32...+140 °F)
Storage temperature
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating
Co
ld)
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating
Dry
Heat)
IEC 60068-2-14 (Test Na, Unpackaged Thermal
Sh
ock)
-40... +85 °C (-40...+185 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged)
5...95% non-condensing
Vibration
IEC 60068-2-6 (Test Fc, Operating)
Operating: 5 g @ 10...500 Hz
Shock
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
DIN rail mount
Panel mount
Operating: 20 g; Nonoperating: 30 g
Operating: 30 g; Nonoperating: 40 g
Emissions (CISPR 11) Group 1, Class A
ESD immunity (IEC61000-4-2) 6 kV contact discharges, 8 kV air discharges
Radiated RF immunity
IEC61000-4-3
10V/m with 1 kHz sine-wave 80%AM from
8
0…2000 MHz
10V/m with 200 Hz 50% Pulse 100%AM at
900 MHz
10V/m with 200 Hz 50% Pulse 100%AM at
1890 MHz
3V/m with 1 kHz sine-wave 80%AM from
2
000…2700 MHz
EFT/B immunity (IEC 61000-4-4)
+2 kV at 5 kHz on communication ports
Surge transient immunity (IEC61000-4-5) ±2 kV line-earth(CM) on communication ports
Conducted RF immunity (IEC61000-4-6) 10V rms with 1kHz sine-wave 80% AM from
150 kHz...80 MHz
