6 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020-C-EN-P - July 2007
Before You Begin
Consider the following when planning your CompactLogix system:
The CompactLogix controller is always the leftmost module in
the system.
The controller must be located within four modules of the
system power supply. Some I/O modules may be located up
to eight modules away from the power supply. See the
documentation for your 1769 I/O modules for details.
The 1769-L32E and 1769-L35E controllers support as many as
16 I/O modules in a maximum of 3 I/O banks with 2
expansion cables.
Each I/O bank requires its own power supply.
Only one controller can be used in a CompactLogix system.
A 1769-ECR right end cap or 1769-ECL left end cap is required
to terminate the end of the communication bus.
Parts List
These components ship with the controller.
You may also use these components with the controller.
Component Description
1769-BA battery
Important: Th
e 1769-BA battery is the only battery you can use
with the 1769-L32E and 1769-L35E controllers.
1747-KY controller key
If you want to Then use this component
Connect a device to the RS_232 port 1756-CP3 or 1747-CP3 serial cable
Connect a device to the EtherNet/IP port standard Ethernet cable with RJ-45 connector
Add nonvolatile memory 1784-CF64 or 1784-CF128 Industrial CompactFlash card
