14 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020-C-EN-P - July 2007
6. Attach the modules to the panel by using the mounting
screws.
7. Rep
eat steps 1...6 for any remaining modules.
DIN Rail Mounting
The controller can be mounted on the following DIN rails:
EN 50 022 - 35 x 7.5 mm (1.38 x 0.30 in.)
EN 50 022 - 35 x 15 mm (1.38 x 0.59 in.)
1. Before mounting the controller on a DIN rail, close the DIN
rail latches.
2. Press the
DIN rail mounting area of the controller against the
DIN rail.
The latches will momentarily open and lock into place.
TIP
If you are mounting more modules, mount only the last one of this group and put the
others aside. This reduces remounting time when you are drilling and tapping the next
group of modules.
ATTENTION
This product is grounded through the DIN rail to chassis ground. Use zinc plated
yellow-chromate steel DIN rail to assure proper grounding. The use of other DIN rail
materials (for example, aluminum or plastic) that can corrode, oxidize, or are poor
conductors, can result in improper or intermittent grounding. Secure DIN rail to mounting
surface approximately every 200 mm (7.8 in.) and use end-anchors appropriately.
