20 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020-C-EN-P - July 2007
In the BOOTP Request History dialog you see the hardware
addresses of devices issuing BOOTP requests.
5. Dou
ble-click on the hardware address of the device you want
to configure.
The New Entry dialog displays the device’s Ethernet Address
(MA
C).
6. Enter the IP address.
TIP
The hardware address is on the sticker located on the left-side circuit board of the
controller next to the battery. See Connect the 1769-BA Battery on page 7 for
instructions on accessing this area.
The hardware address will be in this format: 00-0b-db-14-55-35.
