30 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020-C-EN-P - July 2007
Select the Controller’s Operating Mode
Use the keyswitch on the front panel of the controller to determine
the controller’s operating mode.
Keyswitch
Position
Description
Run •Upload projects.
•Run the program and enable outputs.
•You cannot create or delete tasks, programs, or routines. You cannot create or
delete tags or edit online while the keyswitch is in the Run position.
•You cannot change the mode by using the programming software while the
keyswitch is in the Run position.
Prog •Disable outputs.
•Upload/download projects.
•Create, modify, and delete tasks, programs, or routines.
•The controller does not execute (scan) tasks while the keyswitch is in the Prog
position.
•You cannot change the mode through the programming software while the
keyswitch is in the Prog position.
Rem •Upload/download projects.
•Change between Remote Program, Remote Test, and Remote Run modes through
the programming software.
Remote Run •The controller executes (scans) tasks.
•Enable outputs.
•Edit online.
Remote Program •Disable outputs.
•Create, modify, and delete tasks, programs or routines.
•Download projects.
•Edit online.
•The controller does not execute (scan) tasks.
Remote Test •Execute tasks with outputs disabled.
•Edit online.
