180 Rockwell Automation Publication 2198-UM002G-EN-P - February 2019
Chapter 5 Connect the Kinetix 5700 Drive System
Motor brake conductors are customer supplied. We recommend unshielded
cable up to 90 m (295 ft).
Table 97 - Motor Brake (BC) Connector Specifications
Drive Module
Cat. No.
Pin Signal
Recommended
Wire Size
(AWG)
Strip Length
mm (in.)
Torque Value
N•m (lb•in)
2198-S263-ERSx
2198-S312-ERSx
BC-1 MBRK+
16 7.0 (0.28)
0.22…0.25
(1.9…2.2)
BC-2 MBRK-
TIP Motors used with 2198-S263-ERSx and 2198-S312-ERSx inverters typically
use a brake coil that is not 24V DC. In this case, use a customer-supplied
auxiliary relay to power the customer-supplied brake coil.
