Rockwell Automation Publication 750-IN001O-EN-P - October 2014 23
Prepare for Installation Chapter 2
Table 2 - PowerFlex 750-Series 600/690V Input Drives RF Emission Compliance and Installation
Requirements
Standard / Limits
Drive Frame
Catalog Number
EN61800-3 Category C1
EN61000-6-3
CISPR11 Group 1 Class B
EN61800-3 Category C2
EN61000-6-4
CISPR11 Group 1 Class A
(Input Power
≤ 20 kVA)
EN61800-3 Category C3
(I
≤ 100 A)
CISPR11 Group 1 Class A
(Input Power > 20 kVA)
EN61800-3 Category C3
I > 100 A
Wall Mount Frame 3: 600V (3
Hp and higher.)
20F11xE3P9…20F11xE022
20G11xE3P9…20G11xE022
50 m cable limit with Schaffner
FN258HV-42-33 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m motor cable limit with one input
and one output core.
(1)
30 m motor cable limit with one input
and one output core.
(1)
N/A
Wall Mount Frame 4: 600V
20F11xE027…20F11xE032
20G11xE027…20G11xE032
50 m cable limit with Schaffner
FN258HV-55-34 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m motor cable limit with one input
and one output core.
(1)
30 m motor cable limit with one input
and one output core.
(1)
N/A
Wall Mount Frame 5: 600V
20F11xE041…20F11xE052
20G11xE041…20G11xE052
50 m cable limit with Schaffner
FN258HV-100-35 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m motor cable limit with one input
and one output core.
(1)
30 m motor cable limit with one input
and one output core.
(1)
N/A
Wall Mount Frame 6: 600/690V
20F11xx012…20F11xx144
20G11xx012…20G11xx144
50 m cable limit with Schaffner
FN258HV-100-35 filter (up to 90 kW
drives) or FN3359HV-250-28 filter
(110 kW and larger drives).
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
50 m cable limit with Schaffner
FN258HV-100-35 filter (up to 90 kW
drives) or FN3359HV-250-28 filter
(110 kW and larger drives).
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m motor cable limit with one input
and one output core.
(1)
30 m motor cable limit with one input
and one output core.
(1)
Frame 7: 600/690
20F11xx192…20F11xx289
20G11xx192…20G11xx289
50 m cable limit with Schaffner
FN3359HV-400-99 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
50 m cable limit with Schaffner
FN3359HV-400-99 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m motor cable limit with one input
and one output core.
(1)
30 m motor cable limit with one input
and one output core.
(1)
More Stringent Limits Less Stringent Limits
(1) Rating-specific EMC cores are part of EMC kit numbers 20-750-EMC3-nn and 20-750-EMC4-nn.
