Rockwell Automation Publication 750-IN001O-EN-P - October 2014 91
Lift and Mount the Drive Chapter 3
Figure 52 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Code J)
800 mm Deep Drive with Cabinet Options Bay.
M12 (1/2 in.) Property Class 8.8 anchoring hardware recommended to
fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts may be pre-located and embedded in the
foundation prior to instillation.
➍
➌
2477
(97.5)
2300
(90.6)
1464
(57.6)
800
(31.5)
1030
(40.6)
244
(9.6)
675
(26.6)
556
(21.9)
24
(1.0)
556
(21.9)
1703
(67.0)
➊
480
(18.9)
➋
78
(3.1)
➋
127
(5.0)
1200
(47.2)
➋
127
(5.0)
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
➌ Optional HIM.
➍ Recommended four-hole anchoring.
BOTTOM
TOP
