Chapter 3 Programming and Parameters
Fault and Diagnostic Group (continued)
F686 [DSI I/O Act]
Displays the Drives that are active in Multi-Drive mode.
Value Default: Read Only
Min/Max: 00000/11111
Display: 00000
1 = Drive Inactive, 0 = Drive Active
Drive 0 Actv Digit 1
Drive 1 Actv Digit 2
Drive 2 Actv Digit 3
Drive 3 Actv Digit 4
Drive 4 Actv Digit 5
F687 [HW Addr 1]
F688 [HW Addr 2]
F689 [HW Addr 3]
F690 [HW Addr 4]
F691 [HW Addr 5]
F692 [HW Addr 6]
Shows the MAC address for the embedded EtherNet/IP interface.
Values Default: Read Only
Min/Max: 0/255
Display: 1
F693 [EN IP Addr Act 1]
F694 [EN IP Addr Act 2]
F695 [EN IP Addr Act 3]
F696 [EN IP Addr Act 4]
Shows the actual IP address used by the embedded EtherNet/IP interface at the time. This indicates 0 if no address is set.
Values Default: Read Only
Min/Max: 0/255
Display: 1
255.255.255.255
[EN IP Addr Act 1]
[EN IP Addr Act 2]
[EN IP Addr Act 3]
[EN IP Addr Act 4]

Allen-Bradley PowerFlex 525 Specifications

General

Horsepower	0.5-30 HP
kW	0.4-22 kW
Input Voltage	200-240V AC, 380-480V AC
Enclosure	IP20, NEMA/UL Type 1
Communications	EtherNet/IP
Control Methods	V/Hz, Sensorless Vector
STO	Safe Torque Off (STO)
Output Voltage	0-Input Voltage
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5-95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
