Rockwell Automation Publication 520-UM001A-EN-E - February 2013 123
Programming and Parameters Chapter 3
Fault and Diagnostic Group (continued)
F697 [EN Subnet Act 1]
F698 [EN Subnet Act 2]
F699 [EN Subnet Act 3]
F700 [EN Subnet Act 4]
Shows the actual subnet mask used by the embedded EtherNet/IP interface at the time. This will indicate 0 if no address is set.
Values Default: Read Only
Min/Max: 0/255
Display: 1
255.255.255.255
[EN Subnet Act 1]
[EN Subnet Act 2]
[EN Subnet Act 3]
[EN Subnet Act 4]
F701 [EN Gateway Act 1]
F702 [EN Gateway Act 2]
F703 [EN Gateway Act 3]
F704 [EN Gateway Act 4]
Shows the actual gateway address used by the embedded EtherNet/IP interface at the time. This will indicate 0 if no address is set.
Values Default: Read Only
Min/Max: 0/255
Display: 1
255.255.255.255
[EN Gateway Act 1]
[EN Gateway Act 2]
[EN Gateway Act 3]
[EN Gateway Act 4]
F705 [Drv 0 Logic Cmd]
F709 [Drv 1 Logic Cmd]
F713 [Drv 2 Logic Cmd]
F717 [Drv 3 Logic Cmd]
F721 [Drv 4 Logic Cmd]
In multi-drive mode, this is the logic command being transmitted to drive 0/1/2/3/4/.
In single-drive mode, this is the logic command being used by the drive (whether HS-DSI, EtherNet/IP, or DSI) at the time. If comms control is NOT being used, and the drive is in single-
drive mode, then this parameter will show 0.
Values Default: Read Only
Min/Max: 0/FFFF
Display: 1
