Allen-Bradley PowerFlex 700H Programming Manual

Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 37
Programming and Parameters Chapter 2
UTILITY
Drive Memory
204 [Dyn UsrSet Cnfg]
Enables/Disables dynamic selection of user parameter sets.
Important: In dynamic mode, changes to the parameters are not saved to nonvolatile storage.
Switching user sets restores the values last saved before enabling dynamic mode.
Note: Added for firmware revision 4.001.
Dynamic Mode
1 = Enabled
0 = Disabled
Control Source
1 = [Dyn UserSet Sel]
0 = Digital Inputs
205 [Dyn UsrSet Sel]
Selects user set if [Dyn UsrSet Cnfg] = 0000000000000011.
Important: All digital input selections (parameters 361…366) must be identical in all three
user sets for proper Dynamic User Set operation (even if only two sets are used).
Note: Added for firmware revision 4.001.
1 = Enabled
0 = Disabled
206 [Dyn UserSet Actv]
Indicates the active user set and if the operation is dynamic or normal.
Note: Added for firmware revision 4.001.
1 = Condition True
0 = Condition False
File Group No.
Parameter Name & Description Values
Related
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Ctrl Source Dynamic Mode
Defaultxxxxxxxxxxxxxx00
Bit 1514131211109876543210
UserSet Sel2 UserSet Sel1 User Set Active
00User Set 1
01User Set 2
10User Set 3
11User Set 4
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved UserSet Sel2 UserSet Sel1
Defaultxxxxxxxxxxxxxx00
Bit 1514131211109876543210
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved User Set 3 User Set 2 User Set 1 Dynamic Mode
Defaultxxxxxxxxxxxx0000
Bit 1514131211109876543210
