38 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 2 Programming and Parameters
UTILITY
Diagnostics
209 [Drive Status 1]
Present operating condition of the drive.
1 = Condition True
0 = Condition False
Read Only 210
210 [Drive Status 2]
Present operating condition of the drive.
1 = Condition True
0 = Condition False
Read Only 209
211 [Drive Alarm 1]
Alarm conditions that currently exist in the drive.
Notes: Bit 15 was added for firmware revision 2.001. Bits 7, 8,
and 14 were changed to “Reserved” for firmware revision
3.001.
1 = Condition True/Enabled
0 = Condition False/Disabled
Read Only 212
File
Group
No.
Parameter Name & Description Values
Related
Spd Ref ID 3
(2)
Spd Ref ID 2
(2)
Spd Ref ID 1
(2)
Spd Ref ID 0
(2)
Local ID 2
(1)
Local ID 1
(1)
Local ID 0
(1)
At Speed
Faulted
Alarm
Decelerating
Accelerating
Actual Dir
Command Dir
Active
Ready
Default0000000000000000
Bit 1514131211109876543210
Bits
(2)
Description
Bits
(1)
Description15 14 13 12 11 10 9
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
Ref A Auto
Ref B Auto
Preset 2 Auto
Preset 3 Auto
Preset 4 Auto
Preset 5 Auto
Preset 6 Auto
Preset 7 Auto
TB Manual
Port 1 Manual
Port 2 Manual
Port 3 Manual
Port 4 Manual
Port 5 Manual
Port 6 Manual
Jog Ref
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
Port 0 (TB)
Port 1
Port 2
Port 3
Port 4
Port 5
Port 6
No Local Control
Name
Reserved
Reserved
DPI at 500 k
Motor Overld
Bus Freq Reg
Curr Limit
AutoRst Act
AutoRst Ctdn
Reserved
AutoTuning
DC Braking
Stopping
Jogging
Running
Active
Ready
Defaultxx000000x0000000
Bit 1514131211109876543210
Name
Gate Disable
Reserved
Load Loss
Phase Loss
Motor Therm
Waking
Decel Inhibt
Reserved
Reserved
Heatsink Temp
IntDBRes OH
Anlg in Loss
Str At PwrUp
Power Loss
UnderVoltage
Prechrg Actv
Default0x00000xx0000000
Bit 1514131211109876543210
